EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications
Specifications
Brand Name :
TORICH
Model Number :
EN10305-5
Certification :
ISO8001 ISO14001 TS16949
Place of Origin :
Zhejiang/China
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Ton/Tons per Year
Delivery Time :
20-40days
Packaging Details :
In bundles or in wooden boxes.
Section shape :
Round,Square,Rectangular,Round/Square/Rectangular/Oval.etc
Secondary or not :
Non-secondary
Technique :
ERW,Extruded
Thickness :
0.4 - 50 mm
Application :
Precision Applications
Surface treatment :
Galvanized
Standard :
ASTM,GB,JIS,BS
Grade :
E155 E190 E195 E220 E235 E260 E275 E320 E355 E370 E420 E460 E500 E550 E600 E700
Standard2 :
EN10305-5
Length :
1-12m/as customers' requests
Surface :
Galvanized Coated
Outer diameter(round) :
20 - 677 mm
Product name :
galvanized square tube 4x4 gi square pipe ms square tube price list,Galvanized Square Steel Pipe/Tube
Description

EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

EN10305-5 E155 E190 E195 E220 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

Material

EN10305-5 square steel tubes are designed for precision applications, offering high dimensional accuracy and excellent surface quality. These tubes are manufactured through a process that involves welding and cold sizing, ensuring they meet stringent standards for precision engineering tasks.

Specification

EN10305-5 specifies the requirements for welded and cold-sized square steel tubes. These tubes are often used in applications where precision, strength, and reliability are paramount. The specification covers various steel grades, including E155, E190, E195, E220, and E235, each offering unique mechanical properties to suit different applications.

Key Features

  • High Precision: Manufactured to tight tolerances for applications requiring exact dimensions.
  • Excellent Surface Quality: Smooth finish suitable for further processing or direct use.
  • Versatile Applications: Used in automotive, construction, and mechanical engineering industries.
  • Variety of Grades: Available in multiple steel grades to meet specific mechanical and chemical requirements.

Chemical Composition

The chemical composition of EN10305-5 steel grades is crucial for determining their suitability for various applications. Below is a table presenting the typical chemical composition for these grades:

Element E155 (%) E190 (%) E195 (%) E220 (%) E235 (%)
C ≤ 0.12 ≤ 0.12 ≤ 0.12 ≤ 0.12 ≤ 0.17
Si ≤ 0.35 ≤ 0.35 ≤ 0.35 ≤ 0.35 ≤ 0.35
Mn ≤ 0.70 ≤ 0.70 ≤ 0.70 ≤ 0.70 ≤ 1.20
P ≤ 0.025 ≤ 0.025 ≤ 0.025 ≤ 0.025 ≤ 0.025
S ≤ 0.025 ≤ 0.025 ≤ 0.025 ≤ 0.025 ≤ 0.025

Mechanical Properties

The mechanical properties of EN10305-5 steel grades are essential for understanding their performance under different conditions. The table below outlines the typical mechanical properties:

Property E155 E190 E195 E220 E235
Yield Strength (MPa) ≥ 155 ≥ 190 ≥ 195 ≥ 220 ≥ 235
Tensile Strength (MPa) 290-430 340-480 340-480 410-550 450-600
Elongation (%) ≥ 26 ≥ 24 ≥ 24 ≥ 22 ≥ 20

Steel Grade

The steel grades covered under EN10305-5 are E155, E190, E195, E220, and E235. Each grade offers a balance of strength, ductility, and weldability, making them suitable for various precision applications.

Application

EN10305-5 square steel tubes are used in a wide range of applications, including:

  • Automotive Industry: Components requiring high precision and strength.
  • Construction: Structural elements where dimensional accuracy is critical.
  • Mechanical Engineering: Machinery parts that demand reliable performance.
  • Furniture Manufacturing: Frames and supports that need a smooth finish and precise dimensions.

Possible Alternative Grades

While EN10305-5 offers a range of steel grades, alternative grades may be considered based on specific application requirements. Possible alternatives include:

  • EN10219: Suitable for structural applications with less stringent precision requirements.
  • EN10210: Hot-finished structural hollow sections offering higher strength.
  • ASTM A500: A North American standard for cold-formed welded and seamless carbon steel structural tubing.

EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
EN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision ApplicationsEN10305-5 E235 Welded And Cold Sized Square Steel Tube For Precision Applications

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
