DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910
Specifications
Place of Origin :
Jiangsu China (Mainland)
Brand Name :
WUXI SYLAITH
Certification :
ISO9001
Model Number :
ASTM A213
MOQ :
1MT
Packaging Details :
Exporting package/wooden box package/Or per customers’ requirement
Delivery Time :
3-15 DAYS
Payment Terms :
30%T/T in advance or 100% L/C at sight
Supply Ability :
8000MT/Month
Price :
Negotiable
Technique :
Seamless|Cold-Drawn
Standard :
DIN 17175 ASTM A213 ASME SA210
Size :
customized
Shape :
Round
Materials :
10CrMo910
Surface :
nature
Description

DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910

Quick Detail:

DIN 17175 10CrMo910

Standard: DIN 17175

Grade: 10CrMo910

OD. Range:10mm – 200 mm

Wall thickness: 0.5 mm-20mm

Length: Max length 12m

Description:

Executive Standard

DIN 17175

Materials

DIN 17175 10CrMo910

Ends

PE/Beveled,plastic caps on both ends

Technical Methods

Cold-drawn

Application

boiler,superheater,and heat-exchanger tubes

Certificates

ISO

Third Party Inspection

SGS


Chemical Composition:

STANDARD

GRADE

CHEMICAL COMPOSITION

C

Si

Mn

P,S

Cr

Mo

DIN 17175

St35.8

≤0.17

0.10-0.35

0.40-0.80

≤0.030

/

/

St45.8

≤0.21

0.10-0.35

0.40-1.20

≤0.030

/

/

15Mo3

0.12-0.20

0.10-0.35

0.40-0.80

≤0.030

/

0.25-0.35

13CrMo44

0.10-0.18

0.10-0.35

0.40-0.70

≤0.030

0.70-1.10

0.45-0.65

10CrMo910

0.08-0.15

≤0.50

0.40-0.70

≤0.030

2.00-2.50

0.90-1.20

Mechanical Properties:

Standard

Steel grade

Tensile(MPa)

Yield(MPa)

Elongate(%)

Hardenss

10CrMo910

10CrMo910

480～630

≥280

≥20

20MnG

20MnG

≥415

≥240

≥22

25MnG

25MnG

≥485

≥275

≥20

15CrMoG

15CrMoG

440～640

≥235

≥21

12Cr2MoG

12Cr2MoG

450～600

≥280

≥20

12Cr1MoVG

12Cr1MoVG

470～640

≥255

≥21

12Cr2MoWVTiB

12Cr2MoWVTiB

540～735

≥345

≥18

10Cr9Mo1VNb

10Cr9Mo1VNb

≥585

≥415

≥20

ASME SA210

SA210A-1

≥415

≥255

≥30

≤143HB

SA210C

SA210C

≥485

≥275

≥30

≤179HB

ASME SA213

SA213 T11

≥415

≥205

≥30

≤163HB

SA213 T12

SA213 T12

≥415

≥220

≥30

≤163HB

SA213 T22

SA213 T22

≥415

≥205

≥30

≤163HB

SA213 T23

SA213 T23

≥510

≥400

≥20

≤220HB

SA213 T91

SA213 T91

≥585

≥415

≥20

≤250HB

SA213 T92

SA213 T92

≥620

≥440

≥20

≤250HB

DIN17175

ST45.8/Ⅲ

410～530

≥255

≥21

/

15Mo3

15Mo3

450～600

≥270

≥22

13CrMo44

13CrMo44

440～590

≥290

≥22

Permitted tolerance for OD:

OD

Plus tolerance(+)

Minus tolerance (-)

10.29—48.3

0.4

0.4

<48.3—-≤114.3

0.79

0.79

<114.3—≤219.1

1.59

0.79

<219.1—≤323.9

2.38

0.79

<323.9

±1%

HUACHENG STEEL Boiler Tube and Material/Steel Grade:

HUACHENG STEEL Boiler Tube and Material/Steel Grade

JIS

JIS G 3461 (STB340, STB410, STB510)

JIS G 3462 (STBA12, STBA13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26)

JIS G3454 JIS G3455

JIS G3458

JIS G3460

JIS G 3464 (STBL380, STBL450, STBL690)

ASTM

ASTM A178/A178M (GRADE A, C, D)

ASTM A179/A179M

ASTM A192/A192M

ASTM A213/A213M (T2,T5,T5b, T5c,T9,T11,T12,T17,T21,T22,T23 etc)

ASTM A214/A214M

ASTM A250/A250M

ASTM A1020/A1020M (GRADE A, C, D)

DIN

DIN17175(St 35.8, St 45.8, 17Mn4, 19Mn5, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63,

X20CrMoV121)

GB

GB3087(10#, 20#), GB5310(20G, 20MnG, 25MnG, 15MoG, 20MoG, 15CrMoG, 12Cr1MoVG,

10Cr9Mo1VNbN etc)

Applications:

High pressure, low & medium pressure boiler steel pipes & tubes are suitable for making super-heaters, re-heaters, water wall, and economizer in large-scale power plant.

Product Application

DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910

Packing & Delivery

DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910

DIN 17175 ASTM A213 ASME SA210 Seamless Metal Tubes , Round Steel Pipe 10CrMo910

FAQ


Q1: ARE YOU FACTORY OR TRADER?
A1: Wuxi Sylaith Special Steel Co.,Ltd is a manufacturer of steel pipe and tube since 2010.

We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.


Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?
A2: Seamless Stainless Steel Pipe / Tube, Seamless Carbon Stainless Steel Pipe /Tube,Galvanized Steel Tube witn any Shape and Welded pipes can also be available


Q3: HOW TO GET A SAMPLE?
A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.


Q4. CAN YOU PRODUCE THE PRODUCTS ACCORDING TO MY OWN DRAWINGS?
A4: Yes, we can produce the products according to your drawings that will be most satisfy you.

Q5: HOW TO VISIT YOUR FACTORY?
A5: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
