Socket weld wrought stop valve for oil & gas transfer PN0.6 Mpa to PN80 Mpa DN2 to DN65

Specifications

• Pressure rating: PN0.6 - 80Mpa
• Cutting Ferrule pipe diameter: 2mm -50mm
• Temperature range: -190 ℃ to 220 ℃ (or 70 ℃ to 570 ℃ )
• Suitable fluid media: oil, water, gas and many other corrossive or non-corrosive liquid fluid
• Material of construction: 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
• Flow direction: bi-direction
• Driven: manually driven
• End Port connection: weld socket connection
• Standards: ANSI/AWWA/ASTM/ANSI

Description

No end to applications of pipe fittings, so long no end to the applications of pipes . The list of piping applications continues to expand, its strength, flexibility, very good flow rates and high chemical resistance are qualities which are uniquely suited for the movement or transfer of liquids, steam, solids and air from one point to another. With piping, pipe fittings have many other uses like as follows:

• The transfer of extremely hazardous materials such as chemical and waste.
• Protection of sensitive equipment from high pressures.
• Protection from corrosion and other extreme weather conditions.
• Resistance to household and industrial chemicals.

Materials used:

• Gun Metal
• Cast Steel
• Stainless Steel
• Cast Iron
• Alloy Steel
• Brass
• Bronze
• Aluminum
• Zirconium
• Plastic etc.

Applications

• Chemical / Petrochemical
• Municipal
• Food, Beverage, and Dairy
• Oil and Gas
• Power
• Process Instrumentation
• Pulp and Paper
• Semiconductor
• Marine & dredging
• Sanitation
• Irrigation
• Residential
• Road & highway construction
• Ventilation etc

Competitive advantage

• AutoCAD is used to design products and optimize structures

• Cast Process Design by by Castsoft CAD and CAE

• Strict Manufacturing Process control

• Quality Control Of The Casting Material

• Metal Material Laboratory for test of compositional, metallographic & mechanical property

• Perfect apperance
