SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
Specifications
Place of Origin :
China
Brand Name :
Zhengde Metal
Price :
negotiable
Payment Terms :
Western Union, MoneyGram, T/T
Model NO. :
H beam
Material :
ASTM A36 A572 A992 S235jr/J0/J2 S355jr/J0/J2
Custom Made :
Yes
Custom Cycle :
7-15 Days
Product Name :
H Beam
Payment Term :
30%T/T Advance + 70% Balance
Alloy or Not :
Low Alloy
MOQ :
3tons
Lengh :
Customized
Advantage :
Wear Resistance, Machinability, Easy Welding
Specification2 :
W4 W5 W6 W8
Specification3 :
Ipe AA100 120 140 160 180 200
Standard1 :
ASTM a 6/a 6m-07 BS 4-1:1993 En 10024 JIS G 3192
Transport Package :
Export Standard Package/as Request
Specification :
According to customer requirements
Trademark :
ZHENGDE
Origin :
China
HS Code :
7216101000
Supply Ability :
50000 Tons/Month
Description
Product Description

SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H BeamThe steel structure mainly composed of hot-rolled H-beams has a scientific and reasonable structure, good plasticity and flexibility, high structural stability, and is suitable for building structures that withstand large vibration and impact loads. It has strong resistance to natural disasters and is particularly suitable for building structures in earthquake prone zones. According to statistics, among the devastating earthquake disasters with a magnitude of 7 or above in the world, steel structures mainly made of H-beams have the least degree of damage.

Jumbo Beams
Specification: BS EN 10025-2:2004 Dimension: ASTM A6-11 Tolerance: BS EN 10034:1993
Designation h b s t Area Ix Iy ix iy Zx Zy
mmxmmxkg/m mm mm mm mm cm2 cm4 cm4 cm cm cm3 cm3
1016x305x222 970.3 300.0 16.0 21.1 282 406,500 9,501 37.95 5.80 8,380 633
1016x305x249 980.0 300.0 16.5 26.0 317 481,100 11,750 38.97 6.09 9,818 784
1016x305x272 990.1 300.0 16.5 31.0 347 553,800 14,000 39.96 6.35 11,190 934
1016x305x314 1000.0 300.0 19.1 35.9 400 644,700 16,280 40.15 6.38 12,890 1085
1016x305x349 1008.1 302.0 21.1 40.0 444 722,300 18,460 40.32 6.45 14,330 1222
1016x305x393 1016.0 303.0 24.4 43.9 500 807,700 20,500 40.18 6.40 15,900 1353
1016x305x415 1020.0 304.0 26.0 46.0 529 853,100 21,710 40.17 6.41 16,728 1428
1016x305x438 1026.0 305.0 27.0 49.0 557 909,800 23,360 40.41 6.47 17,740 1532
1016x305x494 1036.0 309.0 31.0 54.0 629 1,028,000 26,820 40.42 6.53 19,845 1736
1016x305x584 1056.0 314.0 36.0 64.0 744 1,246,100 33,430 40.93 6.70 23,600 2130
Our Advantages
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
High Strength
The H-beam produced by Zhengde Metal has high structural strength and light weight; the design style is flexible and rich;
The project construction is fast, the floor area is small, and it is suitable for all-weather construction. It is convenient for machining, structural connection and installation, and easy to dismantle and reuse.
Adequate inventory
The steel structure mainly consists of hot-rolled H-shaped steel, with good plasticity and toughness, and high structural stability
Strong ability to resist natural disasters, especially suitable for building structures in earthquake-prone areas;
Compared with the concrete structure, it can increase the use area of the structure; compared with the welded H-shaped steel, it can obviously save labor and materials, low residual stress, and good appearance and surface quality.
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
Attention to detail
The advantages of H-beam produced by Zhengde Metal:
Full range of steel types: carbon structural steel, low-alloy structural steel, structural steel for hull, weather-resistant structural steel
Good technology: automatic continuous rolling, laser cutting, precise straightening
Large output: 8 production lines with a daily output of 1600 tons
Applicable scene
H-shaped steel is mainly used for beam and column members in industrial and civil structures. for example
1. Steel structure load-bearing brackets of industrial structures
2. Steel piles and supporting structures for underground engineering
3. Industrial equipment structure such as petrochemical industry and electric power
4. Long-span steel bridge components
5. Ship and machinery manufacturing frame structure
6. Girder brackets for trains, automobiles, and tractors
7. Port conveyor belt, high-speed baffle support
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.
Detailed Photos

SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H BeamSS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam

Packaging & Shipping

SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam

Company Profile

SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H BeamShandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Africa, Oceania, Middle East, and Southeast Asia.
SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam

Certifications

SS400 S235jr S355jr S355j2 A36 Galvanized Hot Cold Rolled Mild Carbon Steel H Beam
