Automatic RFID Drop Arm Turnstile Gate , Multi Access Control Barrier Arm Gates
Automatic RFID Drop Arm Turnstile Gate , Multi Access Control Barrier Arm Gates
Specifications
Brand Name :
Goldantell
Model Number :
GAT-105
Certification :
CE/ROHS/FCC/SGS/IS9001
Place of Origin :
Guangdong,China
MOQ :
1pc
Price :
negotiation
Payment Terms :
T/T ,western Union,LC,Paypal
Supply Ability :
2,000pcs per month
Delivery Time :
7 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with export wooden case for outer packing
Communication port :
RS485 ,TCP/IP
Type :
One arm turnstile gate
Size Of product :
1200mm (L) * 165mm (W) * 1000mm (H)
Package size :
1280*255*1070mm
Material :
304 stainless steel/316 stainless steel
Net weight :
65KG/pc
Gross weight :
70KG/pc
Application :
Indoor&outdoor
Delivery :
Sample by air , quantity order by sea
Description

Automatic RFID Drop Arm Turnstile Gate , Drop Arm Barrier Gate Multi

Acess Control

Goldantell Drop Arm Turnstile Introduction&Specification

Goldantell Product Picture

Technical Parameters

Automatic RFID Drop Arm Turnstile Gate , Multi Access Control Barrier Arm Gates

Housing material: domestic standard 304# stainless steel

Working voltage: AC220±10%V 50±10%HZ

Drive motor: DC24V brush motor

Size: 1200mm (L) * 165mm (W) * 1000mm (H)

Arm length: 300 mm

Arm length (optional): 250-500 mm

Direction: single or bi-directional (optional)

Working environment: indoor/outdoor (with a tent over) -10℃～70℃

Relative humidity: ≤90% coagulation free

Time of opening/closing: 1 second

Pass speed: 40 persons/min (open), 25-30 persons/min (closed)

Time to work after power on: 3 seconds

Reset time after break down: 10 seconds

Normal running life: 3 million

Communication interface: standard RS485 interface, distance ≤1200m

Input interface: +12V level signal or pulse width>100ms 12V pulse, drive current>10mA

Goldantell Product Size

Automatic RFID Drop Arm Turnstile Gate , Multi Access Control Barrier Arm Gates

Direction Indicator


The installation position of direction indicator can be adjusted.


The pattern of direction indicator can be customized.

Appearance, Dimension, Material & Surface Finish


Appearance: customized according to customer’s requirement.

Stainless steel thickness of the cabinet: customized within 1.2~2.0mm.


Material of the cabinet: 304 / 316 grade stainless steel.


Surface finish of the cabinet: satin finish / polishing / anti-fingerprint/frosted finish / electroplating / baking

finish.

System Integration


Integrate with access control system required by customers, and built-in reader appointed by customer.


Integrate with visitor management system.


Integrate with ticketing system.

Competitive Advantage


1. More than 10 years powerful ODM/OEM ability,could make product shape design,custom logo,custom

package.


2. we can provide not only product, but also system software management.Save your time and cost.


3. Special service from Goldantell:


For repairing,no need you return back product,only need you take a video,our engineer will instruct you,if

spare parts was damaged in 1 year,we will send you spare parts by fastest express,you no need bear any

fee.


4. Friendly and professional customer service people help you in 16 hours.
