Tunnel Size 650mm * 500mm X Ray Luggage Scanner Cargo Inspection X Ray Security Systems
Tunnel Size 650mm * 500mm X Ray Luggage Scanner Cargo Inspection X Ray Security Systems
Specifications
Brand Name :
Uniqscan
Model Number :
SF6550
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 UNIT
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000 sets per month
Delivery Time :
in one week
Packaging Details :
Wooden box
Name :
x ray baggage inspection system
Model :
SF 6550
X-ray divergence angle :
80 °
Warranty :
2 years
Spatial resolution :
1.0mm Horizontal ；1.0mm Vertical
Tube Current :
0.4~0.7MA（adjustable）
Anode voltage :
100~160KV（adjustable）
Film safety :
for ISO1600
Description

tunnel size 650mm*500mm X ray baggage scanner/cargo inspection x-ray machine

Packaging & Delivery

P Packaging Detail:strong cartoon box or ploywooden case

D elivery Detail:working day after confirm the order

Applications:

  • Airports,
  • Transport terminals,
  • Buildings,
  • Factories (to find needle in clothing, shoes, bags),
  • Courthouses,
  • Embassies,
  • Military installations,
  • Prisons,
  • Hotels,
  • Schools ,
  • Convention centers,
  • Security checkpoints,
  • Special events location

F

X-ray Generator

  • Generate direct: Bottom to up
  • Generate anger: 80 degree
  • Anode Voltage…………100~160KV(adjustable)
  • Anode power…………0.4 to 1.2mA
  • Cooling / Duty Cycle………sealed oil bath with forced air/100%

General Specification

  • Tunnel Size……………650(W)*500(H)mm
  • Conveyor Speed.......0.22m/s
  • Conveyor Max Load……170kg
  • Dose per Inspection……< 1.2μGy/h
  • X-ray divergence angle……………80 °
  • Penetration…………34mm Steel
  • Film Safety…………Guarantee ISO1600 Film
  • X-ray Leakage………0.1 μGy/h (at a distance of 5cm From external housing)

Fatory Pictures:




Tunnel Size 650mm * 500mm X Ray Luggage Scanner Cargo Inspection X Ray Security Systems

Tunnel Size 650mm * 500mm X Ray Luggage Scanner Cargo Inspection X Ray Security Systems
