Parameters

6 Zones

Power Supply: AC85V-264V

Working temperature:-20℃--+50℃

Working Frequency: 4KHZ—8KHZ

Standard External size: 2200mm(H)X800mm(W)X580mm(D)

Standard Internal size: 2010mm(H)X700mm(W)X500mm(D)

Gross weight : 67kg

6 detect sensor zones

5 NO. LED display

1~9 mins back light sleep

1~100 sencitivity setting in every detect zone

8 different frequency surport choice

date display and setting

computer and remote operatetion & network

pass & alarm account memory

connect camera and monitor

password safefy

Alarm Sound Loud for 0~5 kinds surport choise

4 kinds inspection levels surport choise

Characteristic & Function

• 6 mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
• Sensitivity adjustable: Each zone has 100 sensitivity level
• Sensitivity Test piece: One yuan Coin, omnidirectional detection
• Sound & LED alarm: Both Side LED indicator
• Facial Recognition on both sides (Entrance and Exit),with preset database
• Built-in Turnstile on both sides (Entrance and Exit)

Authorized person (white list ): After face recognized, two turnstiles will open at the same time .

Authorized person (black list): After face recognized, the first turnstile opens, when he walks into the device, the first turnstile will be closed. The second turnstile keep close always.

Unauthorized person (common person): No record by face recognized and turnstile will not open.

For 2 and 3, they need waiting for the security guy to confirm safety and authorize by remote control. If he is a regular visitor, the security guy can keep his record and save as Authorized visitor.

• CCTV CAMERA on both sides (Entrance and Exit)

To monitoring all the visitors and recording by DVR

All visitors’ data can be output,including visit time and in/out times.

• Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
• Program Self-diagnostic when power on,no need initial or periodic calibration
• Modularization design,easy for maintenance and replacement.

Ø Locate metals hidden on the body

Ø Head-to-toe uniform detection field

Ø Sensitivity level, three patterns such as high, middle and low for various requirements

Ø visible alarm simultaneously to ascertain layout of metal articles

Ø Count passengers and alarm times automatically

Ø Password protection and only authorized person can operate
