Automatic Pedestrian Entrance Barrier Gate with Access Control System Flap Turnstile

1, Equipment Introduction

Flap turnstile is the high-tech intelligent management product. It is intelligent upgraded product of Tripod Turnstile and Swing gate, with high performance, complete functions, high grade, mainly used in high-end residential, Intelligent Building, hotel, subway, dock, clubs and other high-end places.

The device integrated machinery, electronics, microprocessor control and a variety of identity recognition technology. Compatible with IC card, ID card, bar code card, fingerprints and other identification equipments.

With main control box, wire connection is very clear, easy for installation and maintenance.

Single movement : for single passageway and multi- passageway ; Dual movement: for multi- passageway

2, Main Functions And Features

Standard Product Features:

1) With faulty self-check and alarm function, easy to maintain and use;

2) Operating buttons is built on the main control board, programmable;

3) Mechanical structure, induction of the double anti pinch function, in the process of reduction of the telescopic arm blocked, automatic stop or in the default time motor stops working, the default delay again reset (until reset), and the intensity is very small (less than or equal to 2kg);

4) Sound, light alarm function: containing illegal intrusion, followed by the alarm;

5) Bump prevention function, if not received signal to open the turnstile, swing arm would be automatic locked;

6) Telescopic arm synchronization function;

7) With automatic reset function, after opening, within a schedule time does not pass, the system will automatically cancel the user's access privileges, the standard is open after 5 seconds automatically reset.

8) The passage is automatically opened when power OFF, and would be automatically closed when power ON;

9) Can be connected with a wide variety of reading card equipment, receiving relay switch signal;

10) Can be a one-way or two-way to control people in and out;

11) Remote control and management can be achieved directly through management computer;

Extensible Function:

1) Counting function;

2) Case Extension, telescopic arm material selection.

3, Main Structure And Configuration

Standard body case

Telescopic arm

Main control board

Swallowed card device

Motor

Movement and the transmission part

Infrared Sensors

Alarm (light)

Direction indicator board

4, Standard Technical Parameters

Body case size: 1200*300*980mm

Length of the telescopic arm: 260mm

Maximum passageway width: 600mm

Weight: 140Kg

Case material: stainless steel (No. 304) national standard

Power supply: AC220 ± 10% V, 50HZ

Drive motor: DC motor (24V)

Input interface: relay switch signal or 12V level signal or pulse width ＞100ms 12V pulse signal,

drive current: 10mA

Normal service life: 3 million times

Communication interface: RS485 standard

LED indicator

Card reading window

Access panel

Pass speed: 30-40 passenger / min

Opening and closing time: 0.6 seconds

From power ON into working time: 3 seconds

Automatic reset time after failure: 10 seconds

Working environment: Indoor and outdoor (shed)

Temperature: -10℃- 50℃

Relative humidity: less than 90%, no condensation

Note: All size, shape and function can be customized as per customers’ requirements.
