Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
Specifications
Brand Name :
Jinyan
Model Number :
JY-3300
Certification :
CE, FCC, ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability :
2000pcs/month
Delivery Time :
5-7 days
Packaging Details :
Strong Wooden Case
Resolution :
5000*2048 pixels
Camera :
Sensor: line scan CCD
Power Supply :
24VDC, 3A
Dimmonsion :
1200 x 350 mm
Storaging Temperature :
Range -25 degree to +70 degree
Scanning Technology :
Line scanning
Viewing Angles :
≥170°
Vehicle Speed :
1-65 km/h
Description

Car Security Check Under Vehicle Scanner Checking Surveillance System with High Performance Camera

Features

  • Automatic digital line scan camera, with high-resolution and clarity of the image.
  • The complete image of under vehicle scanning, without any omissions, and the image is clear, complete, no distortion, can be clearly observed that the object is not less than 2mm in diameter.
  • Preparation of inspection processes to meet a variety of on-site needs.
  • Multiple scene image monitoring, recording function. Multi-language user interface design.
  • Strong scalability to easily achieve a variety of system linkage control.
  • ALPR(Automatic Licence Plate Recognition) (Optional)
  • Multiple devices networked control functions(Optional)


Embedded screening parts

Camera: Sensor: line scan CCD
Resolution: 5000*2048 pixels
Power Supply: 24VDC, 3A
Illumination: LED, Power Supply: 24VDC,150W
Size: 1200mm x 350mm 1200mm x 350mm
Storaging Temperature: Range -25 degree to +70 degree

System host

Brand: Grantech (UFO6377H-SP1-953)
CPU: Intel® Core(TM) 2 Duo CPU
P8600@ 2.4GHz or higher
Memory: 2G( optional 4G)
Graphics: Inter(R) Gen 5.0 Integrated Graphics Engine
Hard Disk: SATA2 Hard Disk 500G
Dual LAN (At least one Intel Gigabit)
USB2.0 (Up to 4 pieces)
Monitor: 22inch LCD, resolution up to 1920*1080
Scene Video Record: 4 channel, Compression algorithm of scene video: H264

Controller

Input: 2 channels induction coil
Output: 1 Channel switch type 12VDC
Communication port: RS485, Ethernet(Optional)
Operating Temperature: -10℃ to 55℃

Portable Under Vehicle Surveillance System For Undercarriage Security Inspection

Portable Under Vehicle Surveillance System For Undercarriage Security Inspection
