Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel
Specifications
Brand Name :
ZXTLCD
Model Number :
ZXTLCD-IFP980NIR
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,T/T,MoneyGram,Western Union
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Resolution :
4K Ultra HD
Frame :
Aluminum Alloy
Mic :
8 Array Mic
Operating System :
Android, Optional Windows Dual OS
Writing Method :
pen/finger touch
Screen Size :
98 inch
Description

Interactive board Interactive Flat Panel interactive whiteboard for Education and meeting 4k smart touch board mobile stand Android/Windows interactive flat

major function:

Comprehensive safety lock function, provide U disk lock, screen lock, application software lock, touch lock.

Image mode, provide the setting in the signal source channel, what you see is what you get, no need to exit the menu setting.

Support USB device sharing, Android and computer switch at any time, use at any time, the system suspension menu, sidebar, can be switched according to user needs.

Centralized control, through the external equipment for the whole machine volume, channel, sound, signal source and other functional operation.

Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel

Gone are the days of juggling between devices and cluttered setups. These displays bring everything together with features like real-time annotation, shape-to-text conversion, and picture-in-picture multitasking. Imagine switching between a brainstorming diagram and a live video call without missing a beat, or sharing content wirelessly from a laptop, tablet, or smartphone with a single click. Optional accessories like a built-in OPS PC and height-adjustable stands take customization to the next level, giving users the flexibility to tailor their environment to specific needs. Designed for modern workplaces and classrooms, these tools inspire creativity, enhance productivity, and allow ideas to flow freely.

Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel

Electronic whiteboard software:

1. The teaching mode tool adopts the three-stage design, the left side is the menu bar, the middle side is the commonly used pen and erase tools in the teaching process, and the right side is the page management tools.

2, the software support teaching mode and annotation mode, teaching mode support PPT files inserted into the software, insert the original text, pictures, tables and other objects and animation, at the same time can call all tools directly in the software on the PPT, requirements in use annotation, the application is on each page, at the same time can be used by scanning code to share PPT content, annotation mode can be operated under any software.

3. Pen tools: Provide 6 kinds of pen tools, including pencil, chalk, brush, marker, seal pen, texture pen, etc. Pencil tools can be set as solid line, dotted line, wavy line and other linear, and seal pen can be set with medal shape can be quickly awarded for class rewards.

Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel

Improved Participant Engagement

Utilizing the digital blackboard in meetings makes sessions more interactive, keeping participants engaged and active throughout. It also incorporates multimedia elements to cater to diverse communication preferences, making meetings more accessible and effective.

Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel

name

size

98"

show

Display Area HV (mm)

2160mm ×1215mm

optimum resolution

3840×2160 pixels

Refresh the frequency

60Hz

luminance

300-350cd/m2

contrast ratio

1200:1 / 5000:1 (OC)

Visual Angle

1780(H/V)

Show color

8bit 16.7M/1.07B (10bit)

backlight

DLED

colour gamut ntsc

72%

life span

For 50,000 hours

surface

Body material

Aluminum alloy face frame, oxidation sandblasting process

Front frame color

Black [standard], can be customized silver black or other colors

Front frame glass

Physical tempered grade 7 explosion-proof glass / anti-glare explosion-proof grade 7 tempered glass

Front box pen slot

The two magnetic grooves on the front

Touch parameters

Identification principle

Infrared recognition

Touch embedding mode

Built-in integrated type

The way of writing

Finger, touch pen or other 2mm non-transparent object (full screen writing)

Number of touch points

At 20 o'clock

Touch resolution

32767*32767

Touch precision

±1mm

Single refers to the response speed

＜8ms

Touch number

The theoretical number is infinite

drivers

System automatic identification, no drive

support system

windowsXP /7/8/10/11,Android,MacOS,Linux

working temperature

-10~+50 ℃

communication mode

USB 2.0/USB 3.0

Built-in system

scheme

Amlogic T982

CPU

Quad-core ARM Cortex-A55

GPU

Mali-G52 MP2(2EE)

basic frequency

1.9GHz

internal storage

4G DDR

memory

32GB (EMMC)

Wi-Fi

2.4GHz/5GHz

System version

Android 13.0

Front interface

Enter the port

USB 3.0×3

HDMI×1

TOUCH USB×1

Type-C×1

Prehole position

Auto photosensitive hole 1

Remote control receives the indicator light 1

key

Eight buttons

Switch, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button optional)

The machine interface

Enter the port

RJ45:×1

TOUCH USB:×1

USB3.0:×1

USB2.0:×1

RS232:×1

HDMI IN:×1

AV IN:×2

Other ports

AV OUT :×1

Earphone:×1

SPDIF OUT:×1

Complete machine power consumption

The power of the machine

≤530W

OPS power

≤110W

working voltage

100~240V AC, 50/60Hz

Standby power consumption

≤0.5W

Sound channel stereo

2.0

Dual-channel power

20W / 8 Euro 2 speakers

work environment

service temperature

0~40℃

operation humidity

10%~90% RH

Storage temperature

-20~60℃

Store humidity

10%~90% RH

above sea level

5000 Meters

Size weight

Standard bare machine size length * width * height (mm)

2220×98×1307

Camera bare machine size: length * width * height (mm)

2220×98×1320

Overall machine package dimensions length * width * height (mm)

2370×255×1520

VESA stent hole position (mm)

400(V)×900(H)

Wall hanging thickness (mm)

36mm

net weight

87KG

rough weight

108KG

Single outlet wooden box size: length * width * height (mm)

24503101650 (with base)

Weight (including wooden box)

160KG

Standard list

nameplate (neutral)

1 (affixed on the back of the whole machine)

QR code (Neutral)

1 (at bottom left of front box)

Accessory box (neutral)

×1

Power supply line is 1.8M

1 (98 inches standard with 3 m)

Certificate of qualification (neutral)

×1

Warranty Card (Neutral)

×1

Remote control (battery-free)

×1

Touch pen (magnetic suction)

×2

Wall-hanger (neutral)

×1

Optional list

HDMI line

×1

TOUCH USB Line

×1

Intelligent page turning pen

×1

Wireless screen casting device

×1

traversing carriage

×1

Education Smart Interactive Flat Panel 3840×2160 98 Inch Interactive Panel

If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
