Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education
Specifications
Brand Name :
ZXTLCD
Certification :
CE/Rohs/FCC
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,T/T,MoneyGram,Western Union
Supply Ability :
2000 pcs per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case, carton, flight cases are optional
Model Number :
ZXTLCD-IFP650WIR
Resolution :
4K Ultra HD
Frame :
Aluminum Alloy
Mic :
8 Array Mic
Operating System :
Android, Optional Windows Dual OS
Writing Method :
pen/finger touch
Screen Size :
65 inch
Description


Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education

major function:

1.Intelligent channel identification, automatically jump after inserting the signal source, and prompt the inquiry dialog box.

2. comprehensive safety lock function, provide U disk lock, screen lock, application software lock, touch lock.

3.image mode, provide the setting in the signal source channel, what you see is what you get, no need to exit the menu setting.

4.a variety of sound mode selection, provide the choice of sound device function, can choose the horn, USB microphone, etc., and support the equalizer function.

5.Adaptive ambient light function, which supports adjusting the screen brightness according to the ambient light, and the system supports the anti-blue light eye protection mode to protect the user's eyes.

6.Multi-in-one power button, supporting two-in-one and three-in-one setting modes (realize energy saving, switch OPS computer, and all-in-one machine).

7. support USB device sharing, Android and computer switch at any time, use at any time, the system suspension menu, sidebar, can be switched according to user needs.

Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education

The next generation of office display technology is here, revolutionizing the way teams collaborate and communicate. Interactive Flat Panel Displays (IFPDs) are leading this change, offering unparalleled freedom and convenience for modern meetings. With stunning 4K resolution, intuitive touchscreen interactivity, and seamless connectivity, IFPDs redefine what’s possible in the meeting room.


Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education

Complete machine system requirements:

1, the use of safety appearance design, the whole machine must be all metal shell design, the corners must be curved design, the surface should be no sharp edge or bulge, without any visible internal function module connection line.

2, using aluminum alloy metal frame (good heat dissipation performance, not easy to deform, effectively protect the touch unit), refuse sheet metal, plastic and other front frame, can effectively ensure the structural strength of the front frame.

3. The fuselage of the whole machine has the characteristics of anti-salt fog rust, and the whole machine has the characteristics of anti-vibration and anti-fall, to ensure that the whole machine is not easy to be damaged during transportation or use.

4, front button: switch machine, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button is optional).


Inch Uhd 4K Interact Whiteboard Android Window Dual System Smart Board Interactive Flat Panel For Classroom Education

name

size

65"

show

Display Area HV (mm)

1425mm ×803mm

optimum resolution

3840×2160 pixels

Refresh the frequency

60Hz

luminance

300-350cd/m2

contrast ratio

1200:1 / 5000:1 (OC)

Visual Angle

1780(H/V)

Show color

8bit 16.7M/1.07B (10bit)

backlight

DLED

colour gamut ntsc

72%

life span

For 50,000 hours

surface

Body material

Aluminum alloy face frame, oxidation sandblasting process

Front frame color

Black [standard], can be customized silver black or other colors

Front frame glass

Physical tempered grade 7 explosion-proof glass / anti-glare explosion-proof grade 7 tempered glass

Front box pen slot

The two magnetic grooves on the front

Touch parameters

Identification principle

Infrared recognition

Touch embedding mode

Built-in integrated type

The way of writing

Finger, touch pen or other 2mm non-transparent object (full screen writing)

Number of touch points

At 20 o'clock

Touch resolution

32767*32767

Touch precision

±1mm

Single refers to the response speed

＜8ms

Touch number

The theoretical number is infinite

drivers

System automatic identification, no drive

support system

windowsXP /7/8/10/11,Android,MacOS,Linux

working temperature

-10~+50 ℃

communication mode

USB 2.0/USB 3.0

Built-in system

scheme

Amlogic T982

CPU

Quad-core ARM Cortex-A55

GPU

Mali-G52 MP2(2EE)

basic frequency

1.9GHz

internal storage

4G DDR

memory

32GB (EMMC)

Wi-Fi

2.4GHz/5GHz

System version

Android 13.0

Front interface

Enter the port

USB 3.0×3

HDMI×1

TOUCH USB×1

Type-C×1

Prehole position

Auto photosensitive hole 1

Remote control receives the indicator light 1

key

Eight buttons

Switch, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button optional)

The machine interface

Enter the port

RJ45:×1

TOUCH USB:×1

USB3.0:×1

USB2.0:×1

RS232:×1

HDMI IN:×1

AV IN:×2

Other ports

AV OUT :×1

Earphone:×1

SPDIF OUT:×1

Complete machine power consumption

The power of the machine

≤260W

OPS power

≤110W

working voltage

100~240V AC, 50/60Hz

Standby power consumption

≤0.5W

Sound channel stereo

2.0

Dual-channel power

20W / 8 Euro 2 speakers

work environment

service temperature

0~40℃

operation humidity

10%~90% RH

Storage temperature

-20~60℃

Store humidity

10%~90% RH

above sea level

5000 Meters

Size weight

Standard bare machine size length * width * height (mm)

1485×108×887

Camera bare machine size: length * width * height (mm)

1485×108×900

Overall machine package dimensions length * width * height (mm)

1600×200×1000

VESA stent hole position (mm)

400(V)×500(H)

Wall hanging thickness (mm)

23mm

net weight

33KG

rough weight

41KG

Single outlet wooden box size: length * width * height (mm)

16702651160 (with base support)

Weight (including wooden box)

70KG

Standard list

nameplate (neutral)

1 (affixed on the back of the whole machine)

QR code (Neutral)

1 (at bottom left of front box)

Accessory box (neutral)

×1

Power supply line is 1.8M

1 (98 inches standard with 3 m)

Certificate of qualification (neutral)

×1

Warranty Card (Neutral)

×1

Remote control (battery-free)

×1

Touch pen (magnetic suction)

×2

Wall-hanger (neutral)

×1

Optional list

HDMI line

×1

TOUCH USB Line

×1

Intelligent page turning pen

×1

Wireless screen casting device

×1

traversing carriage

×1

If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
