Specifications
Brand Name :
KeRun
Model Number :
KRS-3493CPG
Certification :
ROHS,SGS,REACH
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
5000pcs/day
Delivery Time :
20-25 working days, can negotiate based on order quantity
Packaging Details :
The actual quantity is based on the actual packing quantity. Inner package: Thin plastic film surround the products to protect it from scratching and water. Outer package: Internationally standard K3 K5 layers corrugated cartons. Packaging materials: EPE
Name :
4 Digit Seven Segment Clock LED Display
Digit height :
0.39 Inch
Digit number :
Four digit
Surface Color :
Black or Grey color
Sreen Size :
40.0 * 14.0 * 7.0 mm
Emitting color :
Pure green
Polarity :
Common cathode
Display function :
Graphics
Life Span :
50000 hours
LED chip :
AlGanlp
Usage :
Indoor use for clock
Application :
Various terminal equipment
Description

Digital Tube 0.39 Inch Clock LED Display 4 Digit Seven Segment 24 Pin

Digital Tube 0.39 Inch 4 Digit Seven Segment Clock LED Display

Product features:

1) Low consumption ,working under low voltage and current .
2) High brightness ,short response time, high frequency.
3) Small size, lightweight, easy soldered ,great Impact resistance.
4) Solid state encapsulation, good stability .
5) Long life ,more than 50,000 hours .
6) Great display effect ,big viewing angle.

Various types based on digit quantity (OEM &ODM available)

Types Type 1 Type 2 Type 3 Type 4
Digit quantity 1 digit 2 digits 3 digits 4 digits

Different size for 4 digit 7 segment led display (OEM&ODM available)

PIN quantity common joint Digit height Display size
1. 10 12 9 8 6 0.28 inches 32.20*10.20*5.80mm
2. 12 12 9 8 6 0.30 inches 30.50*13.00*7.00mm
3. 12 12 9 8 6 0.31 inches 28.00*11.00*5.00mm
4. 12 12 9 8 6 0.36 inches 30.00*14.00*7.20mm
5. 24 2 5 6 8 10 0.39 inches 40.00*14.00*7.00mm
6. 12 12 9 8 6 0.40 inches 40.50*16.00*7.00mm
7. 12 12 9 8 6 0.56 inches 50.00*19.00*8.00mm
9 24 1 3 10 12 0.80 inches 71.80*25.30*8.00mm

Digital Tube 0.39 Inch Clock LED Display 4 Digit Seven Segment 24 pin

Application for Custom LED Digital Displays

1. Industrial Equipment:Industrial ovens, reliability test equipment, analytical instruments, process control equipment, test and measuring instruments, temperature controllers, programmable logic controllers, security systems

2. Networking:Telecommunication equipment, answering machines, telephones, base stations, PBX modems, network cards

3. Outdoor Signs

4. Petrol pump meters

5. Consumer:Audio/video equipment, audio mixers, set top boxes, amplifiers, musical instruments, gaming machines, currency/coin counters, security systems

6. Consumer “White Goods”:Displays for washing machine digital panels, cookers, freezers and dishwashers

7. Medical Equipment,Hospital monitoring systems

8. Transportation

9. Displays, radar detectors, avionics displays

10. Computers and Peripherals:CPU speed indicator, printer front panels, fax machines, copy machines, power supply equipment, cash registers

Digital Tube 0.39 Inch Clock LED Display 4 Digit Seven Segment 24 pin

FAQ

Q1: How can I get the best price?
A1: The price is negotiable. It change according to your quantity or package.
It will be great if you can provide more product details and communicate with us which lead us to offer you the best approach.

Q2: Can I get a sample order?

A2: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q3: What's your MOQ ? Can I mix types?

A3: Our MOQ is 3000pcs since we are manufacturer; however, for some of the specific items, the MOQ can be 1000~2000pcs. Please contact us for details.

Q4: How long to get a sample and the lead time for mass production?

A4: Normally samples lead time is 3~5 days; mass production lead time is 15~30 working days.

Q5: Can you make customized led display??

A5:Yes, we have advantages in customized led display because we have R&D center with professional technical team, and we have more than 10 years experience in this field.
