6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter
Specifications
Brand Name :
KeRun
Model Number :
KRS-25183CUR
Certification :
ROHS,SGS,REACH
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
10000pcs/day
Delivery Time :
20-25 working days, can negotiate based on order quantity
Packaging Details :
The actual quantity is based on the actual packing quantity. Inner package: Thin plastic film surround the products to protect it from scratching and water. Outer package: Internationally standard K3 K5 layers corrugated cartons. Packaging materials: EPE
Type :
14 Segment Led Display
emitting color :
Red
Sreen Size :
25 x 17X 10mm
Polarity :
Common Anode
Display function :
Graphics
Life Span :
50000 hours
certification :
ROHS REACH
Application :
Taximeter
Description

6 Digit 14 Segment LED Display Common Anode 10mm For Taximeter

Super Bright Red 6 Digit 14 Segment Led Display 10mm For Taximeter

Quick details

  • 14 Segment Single-Digit Alphanumeric LED Display
  • Character height are available from 6.2mm (0.25") to 500.00mm(20")
  • long life span
  • OEM / ODM
  • for temperature and humidity indicators
  • Excellent design of outer appearance
  • Strict quality testing before it leave the factory
  • We have our own production workshop and production facility
  • We can customize it according to your requirements

Absolute Maximum Ratings(Ta=25℃)

Parameter Symbol Ratings Unit
Forward Current(per dice) Ipm 20 mA
Reverse Voltage(per dice) Vr 5 V
Power Dissipation(per dice) Pm 80 mW
Operating Temperature Range Topr -40～+85 ℃
Storage Temperature Range Tstg -40～+85 ℃
Solder Temperature(3 sec) Th 260 ℃


Code:R(Super bright Red)

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage(Per dice) Vf If=20mA 1.8 2.5 V
Reverse Voltage(Per dice) Vr Ir=10uA 5 V
Luminous Intensty(Per dice) Iv If=20mA 80 100 mcd
Spectrum With Of Half Value △λ If=20mA 20 nm
Wavelength Dλ If=20mA 622 625 nm
LED working lifetime 100,000hrs Absolute Maximum Rating at Ta=25℃

Inner package: Thin plastic film surround the products to protect it from scratching and water.
Outer package: Internationally standard K3 K5 layers corrugated cartons.
