Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service
Specifications
Brand Name :
EGL
Model Number :
Single SM4 Geophone 10Hz Horizontal​
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 sets
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
10000sets/month
Delivery Time :
5-8 work days
Packaging Details :
Carton
Natural Frequency :
10Hz±5%
Geophone Case :
Horizontal​ Waterproof Land Case
Spike :
75mm
Lead-in Cable :
1 M
Cable O.D :
4.6mm
Connector Type :
Split Spring connector
Price :
Negotiable
Description

Seismic SM4 Geophone 10Hz Horizontal​​ terminated with Split Spring connector

Type Single SM4 Geophone 10Hz
Geophone Direction Vertical Direction / Horizontal Direction
Geophone Type 10Hz
Geophone Case Waterproof Land Case
Spike Steel Spike length75mm
Lead-in

Standard:1mlead-in with O.D.4.6mm

Custom Outer Diameter / Lead Distance available
Connector Type

*Mueller Clips

*Split Spring Clip

*KCK Connector( Male or Female / Push Fit or Lock Ring Type)

*Kooter Connector( Male or Female /KCL male or KCL female or KC2L-4 Dual )

*Other Connector Type available

Single SM4 geophone 10Hz Horizontal​ in land case with spike 75mm, with 1m leader cable,terminated with Split Spring connector.

Horizontal​ Seismic SM4 Geophone 10Hz Corrosion Resistance OEM Service

Type EG-10-II (10Hz SM4)
Natural Frequency ( Hz ) 10 ± 5.0%
Coil resistance(Ω) 375 ± 5.0%
Open Circuit Damping 0.271 ± 5.0%
Damping With Shunt Resistor 0.6 ± 5.0%
Open Circuit Intrinsic Voltage Sensitivity( v/m/s ) 28.8 v/m/s ± 5.0%
Sensitivity With Shunt Resistor ( v/m/s ) 22.7 v/m/s ± 5.0%
Damping Calibration-Shunt Resistance (Ω) 1400
Harmonic distortion ( % ) ＜0.20%
Typical Spurious Frequency (Hz ) ≥240Hz
Moving Mass ( g ) 11.3g
Typical case to coil motion p-p ( mm ) 2.0mm
Allowable Tilt ≤20º
Operating Temperature Range ( ℃ ) -40℃ TO +100℃
Height ( mm ) 32
Diameter ( mm ) 25.4
Weight ( g ) 74
Warranty Period 3 years
