High Frequency Geophone Element Advanced Forecasting OEM Service
High Frequency Geophone Element Advanced Forecasting OEM Service
Specifications
Brand Name :
EGL
Model Number :
EG-100-II
Place of Origin :
CHINA
MOQ :
1 pcs
Payment Terms :
Western Union, T/T,PayPal
Supply Ability :
10000pcs/month
Delivery Time :
5-8 work days
Packaging Details :
Carton
Natural Frequency ( Hz ) :
100Hz ± 10%
Sensitivity With Shunt Resistor ( v/m/s ) :
35.0 v/m/s ± 5%
Coil resistance :
820 Ω ± 10%
Moving Mass :
9.0g
Harmonic distortion ( % ) :
＜0.2%
Typical Spurious Frequency (Hz ) :
≧300Hz
Price :
Negotiable
Description

Geophone 100Hz , Vertical / Horizontal

The Geophone 100Hz (EG-100-II) is a conventional type of moving coil geophone with small error in working parameters and stable and reliable performance. The structure is reasonable in design, small in size and light in weight, and is suitable for seismic exploration of strata and geological environments of different depths.

Type EG-100-II
Natural Frequency ( Hz ) 100 ±10%
Coil resistance(Ω) 820 ±10%
Open Circuit Damping 0.50 ±10%
Open Circuit Intrinsic Voltage Sensitivity( v/m/s ) 35.0 v/m/s ± 5%
Harmonic distortion ( % ) ＜0.2%
Typical Spurious Frequency (Hz ) ≧300Hz
Moving Mass ( g ) 9.0g
Typical case to coil motion p-p ( mm ) 1.2mm
Allowable Tilt ≦20º
Operating Temperature Range ( ℃ ) -40℃ TO +100℃
Height ( mm ) 32mm
Diameter ( mm ) 26mm
Weight ( g ) 80g
Warranty Period 3 years


All parameters specified here in are rated at a temperature 20℃±2℃ .
