Bronze Self Lubricating Bearing For Building Machinery High Density Good Load Capacity
Bronze Self Lubricating Bearing For Building Machinery High Density Good Load Capacity
Specifications
Brand Name :
WHB
Model Number :
P11
Certification :
ISO3547/9001
Place of Origin :
CHINA
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
6000000pcs per month
Delivery Time :
10-20 work days
Packaging Details :
Export carton, wooden case, wood pallet.
Keywords :
Bronze Bearings
Material :
bronze
Apply for :
building machinery
Size :
Customizable
Feature :
high density
Advantage :
good load capacity
Description

Bronze Self Lubricating Bearing For Building Machinery High Density Good Load Capacity

1. Product Description

Bronze Bearings Made of CuSn8 with Lubrication Indents Plain Cylindrical used a kind of high density bronze alloy of special compositions as base, surface of alloy is rolled diamond type of the oil indents or half ball oil indents,is intended for radial, oscillating and axial movements and are especially suited for extra high loads.Therefore,this WHB products have a wide application scope and pracical value in machinery production.

2. Specification

Load capacity Static load 120
N/mm2		 PVvalue limit Oil lubrication 40
N/mm2.m/s
Dymamic load 40
N/mm2		 Dry friction 2.8
N/mm2.m/s
Oscillating 60
N/mm2		 Friction coef μ 0.06~0.15
Speed limit Oil lubrication 5m/s Working temperature -150℃~+250℃
Dry friction 2.5m/s Thermal conductivity 42 W/mk
Coefficient of linearexpansion 11
10 -6/K

3. Application

Bronze Bearings Made of CuSn8 with Lubrication Indents Plain Cylindrical are widely used in mining machinery,building machinery ,agriculture machinery etc.

4. Advantages

This self lubricating bearing is an alloy with high wear resistance and good mechanical properties.this kind of bearing has higher density, load capacity, well wearing performance, longer lifetime.With their thin-wall structure,which doesn't take up too large assembly space.The production of the bushing is by means of advanced fixture and molds,able to suit various engineering applications,making it possiable for the bushing to store large amount of lubricating grease when working.Therefore,the lubrication interval is prolonged and the service hours are effecively lengthened and it has excellent anti-corrosion functions.
