625 Stainless Steel Bearings Corrosion Resistant Self Lubricating Type High Hardness
625 Stainless Steel Bearings Corrosion Resistant Self Lubricating Type High Hardness
Specifications
Brand Name :
WHB
Model Number :
SS
Certification :
ISO3547/ISO9001
Place of Origin :
CHINA
MOQ :
200pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
200000pcs per month
Delivery Time :
15-25 work days
Packaging Details :
Standard export carton, wooden case, wood pallet.
Keywords :
625 Stainless Steel
Material :
stainless steel
Apply for :
hydraulic machinery
Size :
Customizable
Feature :
high hardness
Advantage :
high temperature resistance
Description

625 Stainless Steel Bearings Corrosion Resistant Self Lubricating Type High Hardness

1. Product Description

Valve Self Lube Bearings 625 Stainless Steel Bushings Corrosion Resistant are a triple layers composites one,the base material is excellent 625 stainless steel back and a film of heat resistant power filled PTFE being calendered onto the sintered spherical bronze interlayer. Suitable for dry running, low coefficient of friction, lower wear, good sliding characteristics, forming a transfer film can protect the mating metal surface, suitable for rotary and oscillating movement. The stainless steel backing provides improved corrosio.

2. Specification

Load capacity Static load 280N/mm2 PVvalue limit Oil lubrication 70N/mm2.m/s
Dymamic load 160N/mm2 Dry friction 3.6N/mm2.m/s
Oscillating 80N/mm2 Friction coef μ 0.02~0.15
Speed limit Oil lubrication 5m/s Working temperature -195℃~+450℃
Dry friction 2.5m/s Thermal conductivity 58W/mk
Coefficient of linear expansion

20x

10-6/k

3. Application

Valve Self Lube Bearings 625 Stainless Steel Bushings Corrosion Resistant are widely used in various valve,engineering machinery ,aerospace etc.

4. Advantages

The stainless steel back provides the bush with stronger mechanic strength and load capability. By combining the metals and the polymers together, the products are endowed with the lower friction coefficient and good capacity of anti-abrasion and self-lubrication. Moreover, the stainless steel back can be effectively preventing chemical erosion.It with super strength, extraordinary anti - fatigue characteristics, is widely used in aviation.
