Household Deep Groove Ball Bearing High Precision 6000 Series Low Friction
Household Deep Groove Ball Bearing High Precision 6000 Series Low Friction
Household Deep Groove Ball Bearing High Precision 6000 Series Low Friction
Household Deep Groove Ball Bearing High Precision 6000 Series Low Friction
Specifications
Brand Name :
WHB
Model Number :
GB
Certification :
ISO9001/TS16949
Place of Origin :
CHINA
MOQ :
200pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500000pcs per month
Delivery Time :
10-15 work days
Packaging Details :
Standard export carton, wooden case, wood pallet.
Keywords :
Household Appliances Bearing
Material :
ball bearing steels
Apply for :
electrical machinery
Size :
Customizable
Feature :
high precision
Advantage :
low friction
Description

6200 Household Appliances Deep Groove Ball Bearing High Precision

1. Product Description

6200 Household Appliances Deep Groove Ball Bearing High Precision is the most widely used rolling bearing which based on ball bearing steels material.It is simple in structure and easy to use.It is mainly used to bear radial load, but when the radial clearance of the bearing is increased, it has certain performance of angular contact ball bearing and can bear combined radial and axial load.

2. Specification

Dimensions(mm) Basic Load rating Bearing No. Limiting Speed Weight
d D B R r (kN) (rpm) (kg)
　 　 　 (min) (min) Cr Cor Grease Oil 　
10 26 8 0.3 0.3 4.55 1.95 6000 31000 36000 0.019
10 30 9 0.6 0.6 5.10 2.40 6200 24000 29000 0.032
10 35 11 0.6 0.6 8.10 3.45 6300 22000 27000 0.053
12 28 8 0.3 0.3 5.10 2.40 6001 27000 32000 0.022
12 32 10 0.6 0.6 6.80 3.05 6201 22000 27000 0.037
12 37 12 1 1 9.70 4.20 6301 20000 25000 0.060

3. Application

6200 Household Appliances Deep Groove Ball Bearing High Precision are widely used in Household Appliances,electrical machinery,machine tool,Gearbox etc.

4. Advantages

This series bearings with low frictional resistance, high rotational speed,simple structure, compared with other types, it is easy to achieve higher manufacturing accuracy, so it is easy to produce series in large quantities, and the manufacturing cost is low.Deep groove ball bearing in addition to the basic type, there are a variety of variant structure, such as: with dust cover deep groove ball bearing, with rubber seal ring deep groove ball bearing, deep groove ball bearing with stop groove, deep groove ball bearing with large load capacity with ball notch, double row deep groove ball bearing etc.

Product tags

deep groove ball bearing application

,

deep groove ball bearing

,

single groove ball bearing
