INTRODUCTION
With the continuous development of modern technology, the application of digital display technology will be everywhere. Digital signage relies on the integration of network and multimedia technologies to release and process information in the form of media, and interact with customer feedback in a timely manner. It has been widely used in finance, telecommunications, hospitals, stores, supermarkets, hotels, public places and other fields. The system adopts advanced design concepts and open interfaces, which can integrate a variety of applications.
The digital signage system can count and record the playing time, number of times and playing range of multimedia content, and it can also realize more powerful interactive functions while playing, which brings opportunities for creating new media.
FEATURES
7. Elevator multimedia digital signage This elevator multimedia information publishing system is different from ordinary elevator advertising machines. The system integrates the digital information or voice information of the elevator's upward and downward directions into the multimedia publishing system, and displays the terminal while publishing multimedia advertisements. Up shows elevator going up or down
8. Digital signage of large-scale exhibition centers and competition venues. This system usually uses the existing large screens or newly-built screens of large-scale exhibition centers or competition venues as the terminal for multimedia information display. Through this system, the live or related real-time of competitions or large-scale events can be broadcast live. Information release.
9. Community digital signage
Usually refers to large-scale living, working, or leisure and entertainment concentrated areas, such as large shopping malls, real estate living quarters, software parks, industrial parks, etc., mainly through the system to improve the level of property management and service levels, and expand external information release Channels and enhance the image of the park.
10. Digital signage for the transportation industry
Such as airport, railway station, bus station, bus, subway, etc., the release and operation of multimedia information about flight information, car navigation and other services
SPECIFICATION
System | CPU | Quad core cortex A17,1.8G,RK3288 |
RAM | 2GB | |
Internal memory | 16GB | |
Operation system | Android 8.1 | |
Touch screen | 10-Point capacitive touch | |
Display | Panel | 10.1"LCD IPS panel |
Resolution | 1280*800 | |
Contrast ratio | 800 | |
Luminance | 250cd/m2 | |
Aspect Ratio | ,16:10 | |
Network | WiFi | 802.11b/g/n |
Ethernet | RJ45,100M/1000M | |
Buletooth | Bluetooth 4.0 | |
Interface | Card slot | TF,support up to 32GB |
USB | USB slave | |
USB | USB host x2 | |
HDMI | HDMI output | |
Power jack | DC power input | |
Earphone | 3.5mm earphone with microphone | |
Serial port | USB type serial port | |
RJ45 | RJ45,100M/1000M (POE function,optional,IEEE802.3at) | |
Media play | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K |
Audio format | MP3/WMA/AAC etc. | |
Photo | jpeg | |
NFC | NFC,13.56M(optional) | |
4G LTE | Optional | |
Other | Microphone | Dual microphone |
Speaker | 2*2W | |
Camera | 2.0M/P,front camera(optional Binocular camera) | |
Micphone | yes | |
Language | Multi-language | |
Working temp | 0--40degree | |
Certificates | ||
Color | White/black | |
Accessories | Adapter | Adapter,12V/1.5A |
User manual | yes | |
