Specifications
Brand Name :
Huihao
Model Number :
insulation stud welding pins
Place of Origin :
China
MOQ :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PAYPAL
Supply Ability :
500000PCS per 20 Days
Delivery Time :
5-8 work days
Packaging Details :
CD Weld Studs / Flanged Stud Welding Nails1. 500pcs per bag, 10 bags per carton. 64 cartons per pallet. 2. to be your requirements.
Certification :
ISO
Name :
CD Insulation stud Welding Pins
Finished :
copper coating or galvanized steel
Diameter :
10 Gauge / 12Gauge / 14 Gauge / 3mm
Length :
as your requirement
Material :
mild steel or stainless steel or aluminum
Description

Zinc Coated Steel Insulation Stud Welding Pins with Capacitor Discharge Welder

>>> Introduction To The CD Insulation Stud Welding Pins

CD Insulation Weld Pins are used for attaching insulation to various metals, with the use of a CD welder. After the pin is

welded in place, the insulation is impaled on the pin and secured with a self-locking washer.

10 Ga. (0.135") CD Insulation stud Welding Pins

Material Mild steel with copper coating or galvanized steel are standard, stainless steel and aluminum are available in special order
Diameter 10 Ga. (0.135")
Length 1" 1-1/2" 2" 2-1/2" 3" 3-1/2" 4" 4-1/2" 5" 5-1/2" 6" 7" 8" 9"

12 Ga. (0.105") CD Insulation stud Welding Pins

Material Mild steel with copper coating or galvanized steel are standard, stainless steel and aluminum are available in special order
Diameter 12 Ga. (0.105")
Length 3/4" 1" 1-1/2" 2" 2-1/2" 3" 3-1/2" 4" 4-1/2" 5" 5-1/2" 6" 7" 8"

14 Ga, 2mm (0.080") CD Insulation stud Welding Pins

Material Mild steel with copper coating or galvanized steel are standard, stainless steel and aluminum are available in special order
Diameter 14 Ga, 2mm (0.080")
Length 3/4" 1" 1-1/2" 2" 2-1/2" 3"

3mm CD Insulation stud Welding Pins

Material Mild steel with copper coating or galvanized steel are standard, stainless steel and aluminum are available in special order
Diameter 3mm
Length 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm 65mm 70mm 75mm 100mm 125mm 150mm

---> Length of this style pin should exceed the thickness of the insulation, in order to securely attach the self-locking washer.

---> Nail point is standard - available with "blunt end" as special order.

>>> Application Of The Capacitor Discharge (CD) Insulation stud Welding Pins

CD stud Welding Pins are used specifically by the shipbuilding / offshore industry such as Cable, Pipe and Trapeze Hangers,

Tubing Spacers, Stack Studs and Navy Weld Studs.

zinc Coated Steel Insulation Stud Welding Pins with Capacitor Discharge Welder

>>> Package

1. 500pcs per bag, 10 bags per carton. 64 cartons per pallet. 2. to be your requirements.

>>> Delivery

Sample;DHL/EMS/UPS/TNT/EXPRESS
Large Order:we recommand you by SEA ,or by AIR if in an emergency.
