M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel
Specifications
Brand Name :
HUIHAOKST
Model Number :
M4 STARLOCK WASHER
Certification :
ISO9001-2015
Place of Origin :
CHINA, HEBEI
MOQ :
10000PCS of starlock washer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, alipay
Supply Ability :
1000000 pcs starlock washer per 30 days
Delivery Time :
7 work days
Packaging Details :
small pp bag or plastic box or carton for starlock washer
Name :
M4 Starlock Washer
Size :
M4
ID :
3.5MM
OD :
12MM
Material :
65MN STEEL
Color :
Oxide Black
Usage :
Machinery Equipment, Industrial Production Of Shock Absorption And Insulation
Service :
zhijing.gao 13363891298
Description

Unique Bargains high precision starlock push on locking washers

Specification of M4 Starlock washer

  • Washer Type: Starlock Washer
  • Material: 65Mn Spring Steel
  • Finish: Black Oxide
  • Size: M4
  • Fit Shaft Outer Diameter: 4mm
  • Inner Diameter: 3.5mmm
  • Outer Diameter: 12mm
  • Thickness: 1.5mm
  • Hole Design: 6 Points
  • Package Content: 100(+/-2%)pcs x Starlock Washer

Description of M4 Starlock washer

  • Starlock Washer provides spring force between two attachments and grip shaft firmly in place.
  • These push-on washers create a permanent installation and will lock firmly.
  • 65Mn steel is a perfert material for spring washer due to its good strength. Black oxide finish gives better corrosion resistant performance in dry environments.
  • Widely used in machinery equipment, industrial production of shock absorption, bearings, machinery, etc.
  • The Starlock Washers have teeth that dig into the shaft material, so expect minor scratching.

Technical data of starlock washer

size 2 3 4 5 6 8 10 12
d MIX 1.9 2.9 3.9 4.9 5.9 7.9 9.9 11.9
MIN 1.8 2.75 3.75 4.75 5.75 7.75 9.75 11.75
dc 6 10 12 14 16 17.5 21 27
H 0.7 1.3 1.4 1.55 1.75 1.8 2.2 2.8
h Average 0.25 0.3 0.3 0.4 0.4 0.5 0.7 0.9
MIX 0.275 0.325 0.325 0.43 0.43 0.53 0.74 0.95
MIN 0.225 0.275 0.275 0.37 0.37 0.47 0.66 0.85

M4 Starlock Washer 3.5mm ID 12mm OD Push On Lock Speed Clip 65Mn Steel

Package details of starlock washer

1. 50 pcs , 100 pcs 0r 200 pcs per PP bag

2. 200 pcs or 340 pcs per plastic box

3. to be your requests to design the lable and package
