Specifications
Brand Name :
HUIHAOCUSTOM
Model Number :
mpe-6
Certification :
ISO9001-2015
Place of Origin :
China
MOQ :
1 set
Price :
USD70000
Payment Terms :
L/C, T/T
Supply Ability :
100 sets per 28 days
Delivery Time :
10 work days
Packaging Details :
PET Bottle Washing Plastic Recycling Machine:Standard export package.
name :
Plastic Recycling Machine Plant
Core Component :
Bearing, Gearbox, Motor
machine color :
blue white or designed by customer
key words :
PET Bottle Washing Plastic Recycling Machine
total weight :
25Ton
voltage :
380v/415v/440v
Final product :
PET flakes
Warranty of core components :
1 year
Description

Big Capacity PET Bottle Flakes Washing Dewatering Pelletizing Plastic Recycling Machine Plant

Working Flow OF PET Bottle Washing Plastic Recycling Machine

Belt conveyor → Bale opener machine → Belt conveyor → Pre-washer (trommel) →Belt conveyor → Mechanical label remover → Manual separating table → Metal detector →Belt conveyor → Crusher *2→ Screw conveyor*2 → Floating washer →Screw conveyor → Hot washer chamber *2 →Screw conveyor*2 → High speed friction machine → Screw conveyor → Floating washer → Screw conveyor →Floating washer →Screw conveyor → Horizontal dewatering machine → Drying pipe system → Zig zag air classification system → Storage hopper → Control cabinet

Estimate plant parameters OF PET Bottle Washing Plastic Recycling Machine

Model
CAPACITY
(KG/H)
POWER CONSUMPTION
WATER CONSUMPTION(TON/HOUR)
HUMIDITY CONTENT
MT-300
300KG/H
150KW
3ton/h
＜1%
MT-500
500KG/H
230KW
4-5ton/h
＜1%
MT-1000
1000KG/H
270KW
6-7ton/h
＜1%
MT-2000
2000KG/H
370KW
8ton/h
＜1%
MT-3000
3000KG/H
420KW
10ton/h
＜1%

Final Products (PET Flakes) Quality Reference:

NO.
DESCRIPTION
AA level (ppm)
A level (ppm)
1
PVC content
≤25
≤100
2
PE/PP color flake/metal and other impurity content
≤75
≤100
3
Total impurity
≤100
≤150

Features of main equipments

Belt conveyor

Control method:
frequency control

Bale opener machine

Stirring motor:7.5kw*2

Manual separating table

Dimension (L*W*H): 8000*1000*1200mm

Trommel (pre washer)

Dimension(L*W):5000*1500mm;
Material of barrel: Perforated plate, galvanized treatment

Mechanical Label remover machine

Motor Power:11/22/37KW;
Blade material: Tungsten steel, removable. Removing labels from bottles, label remove rate reach 99%

Floating washer

Dimension(L*W): 4500*1500mm
Made of SUS304 stainless steel

Crusher

Motor power: 37/55/90kw
Fix knives quantity: 4 pc
Moving knives quantity: 10 pc
Knife material: SKD-11(from Japan)
crushing with water

Horizontal dewatering machine

Motor power: 22/37/45kw
Rotation speed reach 1500rpm
Main shaft through dynamic balance treatment
Get rid of water

High speed friction machine

Motor power: 22/37/45Kw
Rotation speed 1200rpm
Main shaft through dynamic balance treatment
