Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Specifications
Brand Name :
YGB,OEM,SKF,NTN
Model Number :
Deep groove ball bearing 6200 2RS
Certification :
ISO9001:2008
Place of Origin :
Wuxi, China
MOQ :
50 pcs
Price :
negotiation
Payment Terms :
T/T , L/C
Supply Ability :
1,000,000pcs per month
Delivery Time :
within 5- 10 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Application :
Machinery Equipments
Material :
stainless steel , Gcr15. carbon steel
Seal Type :
ZZ, 2RS, Z, RS, RZ, 2RZ
Precision :
P0, P6, P5, P4, P2
Virbration :
V1, V2, V3
clearance :
Co, C2, C3, C4
Description


Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing

Description

Model 6300-2RS
Bearing material GCr15/AISI52100/100Cr6
ID*OD*W (mm) 10x35x11mm
Seal type double shields
Lead time Stock or 15-30days
Weight(kg) 0.05
Basic dynamic load ratings/C 10kN
Basic static load ratings/C0 4.8kN
Limiting speed 24000 r/min
Clearance C2,C0,C3,C4,C5
Vibration Level V1, V2, V3, V4
Precision Rating P0,P6,P5,
MOQ No MOQ
Port Shanghai
Grease Mobil polyrex EM, Kyodo Yushi SRL
Payment terms T/T, L/C

Drawing

Miniature 6301 2RS Bearing, 6300 Series Bearing, P0, P6, P5, P4, P2, Gcr15. Carbon Steel Deep Groove Ball Bearing
Usage

1. Electric Motors
Quiet operation realized by proper clearance, recommend the fitting practice. Lower noise lubricants.
Suitable for all speed ranges applications requiring low noise.
2. Automotive Alternators
Longer life in vibrations and high-temperature environments
3. Automotive Starters
High reliability in periodic use of vibrations and high-temperature environments.
4. Compressors
Long-life pump rotors which compress air in low temperature and low viscosity lubrication environments.
5. Blowers
Quiet and stable operation on fan motors at high speed, in environments with vibration and high temperatures
6. Transmissions
Compact design for lightweight to achieve high performance

Advantage
1. It is the combination of 2 machined and polished grooved raceways(inner&outer rings), guiding a number of appropriate balls, separated by a cage
2. This type bearings mainly take the radial load as well as moderate axial load
3. The Vibrating grades are divided into Z1V1, Z2V2, Z3V3.
4. Simple design and suitable for high speeds
5. Large size range and less coefficient of friction
6. Less noise
7. Robust in Operation and normally require little maintenance

1. High swiveling accuracy
2. Low noise
3. Low weight
4. Can be customized according to your needs
5. Can provide small & miniature standard and non-standard ball bearings

6300 Series bearing sizes

BEARING CODE

DIMENSION

LOAD RATING

LIMIT SPEED

INSTALLATION SIZE

d

D

B

r1,2

Cr

Cor

GREASE

OIL

da

min

min

mm

KN

r/min

mm

6301

105

37

12

1

8.58

3.92

19000

24000

17

6302

15

42

13

1

11.4

5.4

17000

20000

20

6303

17

47

14

1

13.5

6.55

16000

19000

22

6304

20

52

15

1

16

7.88

13000

16000

26.5

6305

25

62

17

1.1

22.5

11.5

11000

14000

31.5

6306

30

72

19

1.1

26.7

14.9

9000

11000

36.5

6307

35

80

21

1.5

33.4

19.2

8500

10000

43

6308

40

90

23

1.5

40.8

24

7500

9000

48

6309

45

100

25

1.5

48.9

29.3

6700

8000

53

6310

50

110

27

2

57.6

35.3

6300

7500

59

6311

55

120

29

2

71.6

44.8

5600

6700

64

6312

60

130

31

2.1

81.9

51.8

5000

6000

71

6313

65

140

33

2.1

92.8

59.7

4800

5600

76

6314

70

150

35

2.1

104

68

4500

5300

81

6315

75

160

37

2.1

113

77

4300

5000

86

6316

80

170

39

2.1

123

86.5

3800

4500

91

6317

85

180

41

3

133

96.6

3600

4300

98

6318

90

190

43

3

143

107

3400

4000

103

6319

95

200

45

3

153

118

3200

3800

108

6320

100

215

47

3

173

140

3000

3600

113
