2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing
Specifications
Brand Name :
SKF, TNT, YGB, OEM
Model Number :
2312
Certification :
ISO 9001:2008
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T or LC
Supply Ability :
10,000pcs per month
Delivery Time :
5-10 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden，in case for outer packing. All it's standarded
Product name :
Self aligning mounted ball bearing
Number of row :
Double Row
Precision rating :
P0 P1 P4 P5 P6
Seals type :
OPEN
Application :
Low Noise Motors
Description

High quality 2312 2312K 2313 Double Row Self-Aligning Radial Ball bearing

Product description:

Product name 2312 self-aligning ball bearing
Brand YGB, OEM
Basic dynamic load rating 87.1 kN
Basic static load rating 28.5 kN
Reference speed 9500 r/min
Limiting speed 7000 r/min
d(mm) 60
D(mm) 130
B(mm) 46
Cage Nylon/Steel/Brass cage
Material Chrome steel /stainless steel
Number of rows Double row
Delivery time <5000pcs,within 5 days after payment

Product Description

In a self-aligning bearing, the inner ring has two raceways and the outer ring has a single spherical raceway with its center of curvature coincident with the bearing axis. Self-Aligning Double Row Ball Bearings are designed to work in applications where severe misalignment exists whether from mounting or shaft deflection. The concave raceway of the outer ring in combination with two rows of balls operate over a wide range of contact angles.

The drawing:

2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing

2312 2312K 2313 Double Row Radial Ball Bearings , Self Aligning Roller Bearing

Spherical Roller Bearing Information:

(Universal Series 12xx, 13xx, 22xx, 23xx)

1. Roller bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads.
These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered.
2. All roller bearings are open, shielded, or sealed.
3. Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use.
4. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan.

5. This structure of type is Cylindrical and tapered holes.

Advantage:

(1)High-Quality Steel-Ultra clean steel to extend bearing life by up to 80%.

(2)Advanced Grease Technology

(3)High-Grade Balls - Quiet and smooth operation even at high speed.

(4)Super Finished Raceways - Specially honed to minimize noise and improve lubricant distribution and life.

Application:

Suitable for precision instruments, low noise motors, automobiles, motorcycles, and general machinery, etc. It is the most widely used type of bearing in the machinery industry.

Contact us:

YGB Bearing Co., Ltd is an integrated and modern enterprise engaged in the R&D, manufacture, and sales of high-quality bearings. We are the Bearing experts serving the OEM throughout China as well as the international markets, such as deep groove ball bearing, spherical roller bearing and tapered roller bearing as well as other kinds of bearings.

If you need to be free to contact us.
