Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types
Specifications
Brand Name :
SKF, TNT, YGB, OEM
Model Number :
1208
Certification :
ISO 9001:2008
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T or LC
Supply Ability :
10,000pcs per month
Delivery Time :
5-10 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden，in case for outer packing. All it's standarded
Name of products :
Self Aligning Ball Bearing
Number of row :
Single Row
Precision rating :
P0 P6 P5 P4 P2
Seals type :
OPEN 2RS ZZ
Material :
Chrome steelGcr15, stainless steel
Size(mm) :
40*80*18
Feature :
Stable Performance Low Voice
Description

Steel plate and synthetic resin cage Self Aligning Ball Bearing 1206 1207 1208K 1209 k all types

This type can bear a large radial load and a certain axial load. The raceway of the outer ring of this kind of bearing is spherical, so it has the ability of alignment. When the axis is bending or inclined, and the relative inclination between the inner ring center line and the outer ring centerline does not exceed 1 ~2.5, the bearing can still work.

There are two kinds of inner holes of self-aligning ball bearings: cylindrical and conical. The taper of a conical bore is 1:12 or 1:30. In order to enhance the lubrication performance of bearings, annular grooves and three oil holes are machined on the outer ring of bearings.

The basic info:

Cylindrical bore self-aligning ball bearing (10000 type)
Bearing Type: self-aligning ball bearing New domestic model: 1208
Domestic old model: 1208
Inner diameter (mm): 40
Outer diameter (mm): 80
Width (mm): 18
Grease lubrication speed (r/min): 7500
Cor(kN): 6.50
Cr(kN): 19.2
Oil lubrication speed (r/min): 9200
Weight (KG): 0.417

Steel Plate And Synthetic Resin Cage P4 Bearing 1206 1207 1208K 1209 K All Types

Advantages of High sale self-aligning ball bearing 1205 1206 1207 1208K 1209 k all types bearing

Sustain radial, axial, or composite loads. Steel plate and synthetic resin cage Self Aligning Ball Bearing 1206 1207 1208K 1209 k all types

Provide both high-running accuracy & high-speed operation

Can replace high-speed angular contact ball bearings

Simple design

Maintenance-free Longer service life

Application:

For transmission, instrumentation, electrical, household appliances, internal combustion engines, transport vehicles, agricultural machinery, construction machinery, engineering machinery, roller-skating shoes, yo-yo, etc.

Contact us:

YGB Bearing Co., Ltd is an integrated and modern enterprise engaged in the R&D, manufacture, and sales of high-quality bearings. We are the Bearing experts serving the OEM throughout China as well as the international markets, such as deep groove ball bearing, spherical roller bearing and tapered roller bearing as well as other kinds of bearings.

If needs be free to contact us.
