7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
Specifications
Brand Name :
YGB,OEM,SKF,NTN
Model Number :
7304B
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
negotiation
Price :
negotiation
Supply Ability :
10,000pcs per month
Delivery Time :
5-10 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Payment Terms :
T/T or LC
Model :
7304B
Packing :
10pcs in a plastic keg + carton or individual box + carton
Grease :
Mobil polyrex EM,Kyodo Yushi SRL
Seal type :
open,double seals,double shields
Number of row :
Single
Size(mm) :
20 X 52 X 15 mm
Description

Angular contact bearings 73 series bearings with high precision low nosie for motors used

Description :

Angular contact ball bearings are self-retaining units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet metal or brass cages. The raceways of the inner and outer rings are offset from each other along the bearing axis. The bearings are available in open and sealed designs. Their angular adjustment facility is very limited.

Model 7304B
Bearing material GCr15/AISI52100/100Cr6
ID*OD*W (mm) 20 X 52 X 15 mm
Seal type double shields
Lead time Stock or 15-30days
Weight(kg) 0.14
Basic dynamic load ratings/C 17.4 kN
Basic static load ratings/C0 9.5 kN
Limiting speed 16000 r/min
Clearance C2,C0,C3,C4,C5
Viberation Level V1,V2,V3,V4
Precision Rating P0,P6,P5,
MOQ No MOQ
Port Shanghai
Grease Mobil polyrex EM,Kyodo Yushi SRL
Payment terms T/T, L/C



Drawing:
7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm
Other Models:

Model No. ID mm OD mm Width mm
7301-B-JP 12 37 12
7301-B-TVP 12 37 12
7302-B-TVP 15 42 13
7302-B-JP 15 42 13
7303-B-TVP 17 47 14
7303-B-JP 17 47 14
7304-B-MP 20 52 15
7305-B-MP 25 62 17
7306-B-MP 30 72 19
7307-B-MP 35 80 21
7308-B-MP 40 90 23
7309-B-MP 45 100 25
7310-B-MP 50 110 27
7311-B-MP 55 120 29
7312-B-MP 60 130 31
7313-B-MP 65 140 33
7314-B-MP 70 150

35

Payment

1: T/T: 30% as deposit and 70% balance after get copy of B/L.
2: L/C (cannot for branded bearings.)
3: Discuss together between buyer and supplier.

FAQ

Q: Can I get free samples for test from your company?
A: Standared samples are avialable, all customers must pay the shipping cost

Q: What is the MOQ of your products?
A: The MOQ of our products is 1 pcs for one model one size

Q: We'd like to print our Logo on the appliances. Can you make it?
A: We provide OEM service which including logo printing, and carton design.

Q: How about the delivery time?
A: 30 - 45 days after the receipt of deposit and confirmation on all designs based of normal condition.

Our service :

7304B High Precision Roller Contact Bearing For Motors 20 X 52 X 15 mm




Dear friend, any questions please feel free to contact us, let's learn and grow together in bearing worlds!
