12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate
12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate
12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate
12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate
Specifications
Brand Name :
SupAnchor
Model Number :
R38N
Certification :
ISO, SGS, ITB, IBDIM
Place of Origin :
Sichuan, China
MOQ :
3 meters
Price :
1 - 30 USD
Payment Terms :
L/C, T/T
Supply Ability :
200,000 meters per month
Delivery Time :
1 to 6 weeks
Packaging Details :
Packed in bundle with package paper.
Name :
SupAnchor R38N Self Drilling Anchor Plate
Anchor Bar Type :
R38
Size (mm) :
200 x 200
Thickness (mm) :
12
Hole diameter (mm) :
41
Unit Weight (Kg/m) :
3.60
Description

R38 Domed Plate For Self Drilling Anchor Bar R38N In Soil Nailing 12mm thickness

Features

Anchor plates are made of cast iron, sometimes wrought iron or steel, and are often used on brick or other masonry-based buildings, tunnels, mines, etc.

SupAnchor® self drilling anchor system is a bolting solution for difficult ground and rock conditions. The system enables drilling and grouting in one operation, making much saving in jobsite and project time.

Advantages

• A high rate of installation

• Self drilling system eliminates the requirement for a cased borehole

• Installation with simultaneous drilling and grouting possible

• Easy installation in all directions, also upwards

• Suitable for working in limited space, height and in areas of difficult access

• Simple post grouting system

Technical Data

Anchor Plate R38N/21 R38N/19 R38/550 R38/600 R38/660
Size (mm) 200 x 200 200 x 200
Thickness (mm) 12 16
Hole Diameter (mm) 41 41
Unit Weight (kg) 3.60 4.80
Options of Anti-corrosion Hot-dipped Galvanization / Epoxy Coating / SupCoat
*Hot-dipped Galvanization: ISO 1461.

*Epoxy Coating: Bending properties up to standard ISO 1519; Impact properties up to standard ASTMD 2794; Adhesion up to standard

ISO 2409:2007.

*SupCoat: HDG + EC


Anchor Bar and Accessories

12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate

Job sites
12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate

12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate

12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Plate

SubNumbers

10 Years - The average seniority > 10 years, which is not common in anchor manufacturing industry.

20 Years - 20 years of exporting experience, familiar with different product standards from different

customers and countries.

26 Years - 26 years of exploration and development, SupAnchor has become the No.1 SDA bar

manufacturer in Asia.

60 Countries - customers from 60 countries. Our self drilling anchor systems have been used by

customers from 50 countries all over the world, including America, Chile, Germany,

Australia India, etc.

1,500 Projects - SupAnchor’s products have been widely used in over 1500 massive projects.

Quality System

QC Procedure
SupAnchor 12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor Platehas its own quality tracking systems. Every batch of anchor bar has its unique batch
number, which can be tracked from raw materials till installation.
Being the 12mm Thickness 41mm Hole Dia R38 Domed Self Drilling Anchor PlateNo.1 exporter of SDA bars in Asia, quality control has been always SupAnchor’s biggest
concern. Our quality testing equipment number ranks first on the list in anchor manufacturing industry
in Asia. It is SupAnchor’s mission to support your construction with products of high quality.
Quality Inspection Rate
Mechanical strength test ratio >= 3%
Dimensions test ratio = 100%
Surface inspection ratio = 100%
