Bimetal Bushing JF804 Wrapped Bronze Steel And CuSn6Ni9 Material With Lock Ring
JF-804 Sliding layer can be machined with lubricating grooves and/or with grease indents
Very good corrosion resistance
Steel+CuSn6Ni9
The main applications are in Automotive and Industrial products.
Automotive: McPherson struts and shock absorbers, doors, bonnets and tailgate hinges, steering columns, clutches, gearbox selector fork guides, wiper arms, power steering pumps, pedal bushes, ABS equipment, etc.
Industrial: Aerospace, agricultural equipment, construction equipment, material handling equipment, forming machines-metal, plastic and rubber, office equipment, medical and scientific equipment, packaging equipment, pneumatic and hydraulic cylinders, pumps and motors, railroad and tramways, textile machinery, valves, etc.
Bimetal Bushings‘ applications for King pin, Spring eyes, Trunion, Piston pin, Rocker arm, Connecting rod, Transmission system, Distributor, Clutch, pilot, Starter, Generator, Oil pump, gear pump, Water pump, Cam shaft, Intermediate shaft, Balance shaft.
Bimetal Washers’ applications for Main bearing, Cam shaft, Crank shaft, Distributor, Transmission system, Oil pump, Ram pump, vane pump and other applications.
Engine Bearings’ application for Cam shaft, Crank (main), Con. Rod (big end) and other applications of engine bearing.
Features:
- An inner liner prevents wear through - With a dual-layer design (whether metal or a metal/polymer mix), the strength of the material is dispersed evenly throughout the entire bearing unit. Why is this important? The unit will have the same thickness and same strength to prevent weak spots and wear through. Two layers result in a more reliable performance for a longer service timeline.
- More layers protect against debris - As we discuss in our debris contamination is a leading cause of bearing failure. Debris can be generated from machining such as shavings and even environmental contamination. A bimetal design has more surface area to resist debris. And in the rare case of a liner wear, the secondary layer is also lubricated to protect expensive manufacturing equipment from damage.
- Lubrication x2 - (whether too much or too little,) is the number one cause of bearing failure. A bimetal or dual design provides an extra layer of lubrication protection. With more lubrication, there’s less heat generated, and less friction. Well lubricated bearings are also well designed for extended service life.
- Durability and strength - Sintered bearing liners bring different levels of durability and fatigue strength. For instance, auto engine and transmission applications have primarily low loads yet high rotating speeds. A TriSteelsteel-backed bearing with a CuPb30 liner will give a load capacity of 3600 psi, speed to 2900 fpm Hardness: HB30-45, Temperature: -40 to +325F. 0.08-0.16, plus low friction and good dry breakaway properties.

Tech. Data
Max.Load | Static | 250N/mm² | Alloy Hardness | HB 60-100 |
| 140N/mm² |
Temp | -40℃~+250℃ |
Coefficient of friction | 0.05~0.12 |
Max.Speed | Max.Speed | 2.5m/s | Thermal conductivity | 60W(m*k)-1 |
Max.PV | Max.PV | 2.8N/mm²*m/s |
Shear strength | Shear strength | 170N/mm² |
Coef.of yhermal exoansion | 14*10-6K-1 |
