Specifications
Brand Name :
KINGDA
Model Number :
AB24EJ
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
(TBD)USD
Payment Terms :
T/T
Supply Ability :
NO LIMITED
Delivery Time :
60 Days
Packaging Details :
Export packing
Platform Size :
2.44m x 0.91m
Weight :
15,000kg
Description

Electrical Articulating Boom Lift Maximum Platform Height 24.2m

Product Features


1. The electrical articulating boom lift stands as a pinnacle of efficiency and versatility in aerial work platforms, offering unmatched performance for tasks at elevated heights. With its robust construction and advanced features, including four-wheel drive and a sophisticated hydraulic system, it ensures optimal manoeuvrability across various terrains.
2. Engineered with safety as the top priority, this articulating boom lift incorporates a comprehensive array of safety features, including load sensing systems and fault diagnosis systems, providing operators with peace of mind and confidence during operations.
3. Powered by an electrical engine, this articulating boom lift boasts exceptional power and performance, allowing it to handle steep grades and challenging environments with ease, making it ideal for a wide range of applications.
4. Equipped with intuitive controls and ergonomic design, operators can navigate the articulating boom lift with precision and efficiency, enhancing productivity and reducing downtime on the job site.
5. From construction sites to industrial facilities, this articulating boom lift excels in providing safe and efficient access to elevated work areas, ensuring optimal performance and reliability in demanding environments.

80 Foot Articulating Boom Lift Platform 24.2m Tire Size 36X14-20 Machine 15000Kg AWP

Model AB24EJ
Size Metric
Maximum Working Height 26.2m
Maximum Platform Height 24.2m
Maximum Horizontal Outreach 15.4m
Maximum Up & Over Clearance 10.2m
Platform Size 2.44X0.91m
Length-Stowed 10.65m
Width-Stowed 2.48m
Height-Stowed 2.91m
Wheelbase 3m
Ground Clearance 0.31m
Performance
Maximum Lifting Capacity 230Kg
Maximum Platform Occupancy 2ppls
Platform Rotation 士90°
Vertical Jib Rotation 135°
Turntable Rotation 360°Continuous
Drive Speed-Stowed 4.2Km/h
Drive Speed-Raised 0.8Km/h
Gradeability 30%
Maximum Working Slope
Turning Radius (inside) 2.76m
Turning Radius (outside) 6.09m
Drive &Steer Mode 4X4X2
Tire Size 36X14-20
Power
Battery 80V/560/Ah
Pump Motor Power 23Kw
Drive Motor Power 4X4
Charger 80V/80A
Control Voltage
Weight
Machine Weight 15000Kg
Standard Compliance
EN280 GB25849

※ The picture and technical information may vary by the update policy, the changes will be without prior notice.

The Aerial Work Platform Production Line



1. Full Capacity for Production Processing: Professional Manufacturing Equipments to ensure customers one-stop cooperation
2. High Quality & Efficiency: High consistency of processing quality, to ensure efficiency and high precision machining characteristics

3. It plays a crucial role in providing safe and efficient equipment for various industries, such as construction, maintenance, and utilities. The production line's commitment to quality and innovation ensures that customers receive reliable and high-performing aerial work platforms for their specific needs.
