S25FL064P0XMFA000 Flash Memory Chips 16-SOIC Package 64Mbit 3.0V SPI Single power supply operation
S25FL064P0XMFA000 Flash Memory Chips 16-SOIC Package 64Mbit 3.0V SPI Single power supply operation
S25FL064P0XMFA000 Flash Memory Chips 16-SOIC Package 64Mbit 3.0V SPI Single power supply operation
S25FL064P0XMFA000 Flash Memory Chips 16-SOIC Package 64Mbit 3.0V SPI Single power supply operation
Specifications
Brand Name :
Infineon / CYPRESS
Model Number :
S25FL064P0XMFA000
Place of Origin :
original
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
999999
Delivery Time :
1 - 3 days
Packaging Details :
standard
Memory Type :
Non-Volatile
Memory Format :
FLASH
Memory Size :
64Mbit
Memory Organization :
8M x 8
Operating Temperature :
-40°C ~ 85°C (TA)
Voltage - Supply :
2.7V ~ 3.6V
Description

S25FL064P0XMFA000 Flash Memory

Chips 16-SOIC Package 64Mbit 3.0V SPI Single power supply operation

Memory Type
Non-Volatile
Memory Format
FLASH
Technology
FLASH - NOR
Memory Size
64Mbit
Memory Organization
8M x 8
Memory Interface
SPI - Quad I/O
Clock Frequency
104 MHz
Write Cycle Time - Word, Page
5µs, 3ms
Voltage - Supply
2.7V ~ 3.6V
Operating Temperature
-40°C ~ 85°C (TA)
Mounting Type
Surface Mount
Package / Case
16-SOIC (0.295", 7.50mm Width)
Supplier Device Package
16-SOIC

General Description

The S25FL064P is a 3.0 Volt (2.7V to 3.6V), single-power-supply flash memory device. The device consists of 128 uniform 64 kB sectors with the two (Top or Bottom) 64 kB sectors further split up into thirty-two 4 kB sub sectors. The S25FL064P device is fully backward compatible with the S25FL064A device.


The device accepts data written to SI (Serial Input) and outputs data on SO (Serial Output). The devices are designed to beprogrammed in-system with the standard system 3.0-volt VCC supply.

Performance Characteristics


 Speed


– Normal READ (Serial): 40 MHz clock rate
– FAST_READ (Serial): 104 MHz clock rate (maximum)
– DUAL I/O FAST_READ: 80 MHz clock rate or
20 MB/s effective data rate
– QUAD I/O FAST_READ: 80 MHz clock rate or
40 MB/s effective data rate


 Power saving standby mode


– Standby Mode 80 μA (typical)
– Deep Power-Down Mode 3 μA (typical)
