TPS63070RNMR Power Management ICs 2V 16V Buck-Boost Converter 3.6A Switch Curren
TPS63070RNMR Power Management ICs 2V 16V Buck-Boost Converter 3.6A Switch Curren
Specifications
Brand Name :
TI
Model Number :
TPS63070RNMR
Place of Origin :
original
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
999999
Delivery Time :
1-3 days
Packaging Details :
standard
Voltage - Input (Min) :
2V
Voltage - Input (Max) :
16V
Voltage - Output (Min/Fixed) :
2.5V
Voltage - Output (Max) :
9V
Current - Output :
3.6A (Switch)
Frequency - Switching :
2.4MHz
pn :
TPS63070RNMR
Description

TPS63070RNMR Power Management ICs 2-V to 16-V Buck-Boost Converter With 3.6-A Switch Curren Package 15-PowerVFQFN

Product Status
Active
Function
Step-Up/Step-Down
Output Configuration
Positive
Topology
Buck-Boost
Output Type
Adjustable
Number of Outputs
1
Voltage - Input (Min)
2V
Voltage - Input (Max)
16V
Voltage - Output (Min/Fixed)
2.5V
Voltage - Output (Max)
9V
Current - Output
3.6A (Switch)
Frequency - Switching
2.4MHz
Synchronous Rectifier
Yes
Operating Temperature
-40°C ~ 125°C (TJ)
Mounting Type
Surface Mount
Package / Case
15-PowerVFQFN
Supplier Device Package
15-VQFN-HR (3x2.5)

Features
• Input Voltage Range: 2.0 V to 16 V
• Output Voltage Range: 2.5 V to 9 V
• Up to 95% Efficiency
• +/- 1% dc accuracy in PWM mode
• +3% / -1% dc accuracy in PFM mode
• 2 A Output Current in Buck Mode
• 2 A Output Current in Boost Mode
(VIN = 4 V; Vout = 5 V)
• Precise ENABLE input allows
– user defined undervoltage lockout
– exact sequencing
• Automatic Transition Between Step Down and
Boost Mode
• Typical Device Quiescent Current: 50 μA
• Fixed and Adjustable Output Voltage Options
• Output Discharge Option
• Power Save Mode for Improved Efficiency at Low
Output Power
• Forced Fixed Frequency Operation at 2.4 MHz
and Synchronization Option
• Power Good Output
• VSEL simply allows output voltage change
• Load Disconnect During Shutdown
• Overtemperature Protection
• Input / Output Overvoltage Protection
• Available in QFN Package
