The main and side beams of our removable gooseneck lowboy trailer are made of HG60 high-strength structural steel.
The side beam is designed as "H" shape. The yield strength of HG60 steel is ≥620Mpa, which is more durable and stronger than ordinary steel, and its bearing capacity is twice that of other ordinary steels.
Dimension(L*W*H) | 14400*3000*3400mm ( Details will be according to the drawing) |
Loading capacity | 50 ton |
Axle | 4 axles, TITAN brand |
Tire | 16 pcs |
Frame | Material: Q 550 high strength steel, Main beam height: 450mm upper plate thickness:27mm, down plate thickness: 27mm, middle plate: 18mm |
Working platform | 7600mm |
Floorplate | 5mm, diamond plate |
Suspension | Spring suspension |
Braking system | WEBCO |
King Pin | 2" 50# or 3.5" 90# |
Electric System | 24V, LED light |
Color | white, blue, yellow, green, red, color optional |
Pay attention to something of the lowboy gooseneck trailer for sale:
Cargo weight: Please select the correct model to transport your cargo. If you plan to transport more than 60 tons of cargo, please consider buying a lowboy equipment trailers.
The 100 ton lowboy trailer has a high load capacity and can transport heavy objects. In addition, the lower deck ensures that heavy objects remain stable during transportation.
Cargo dimension: It is important to consider the dimensions of your cargo when choosing a detachable trailer model. Consider the width and height, especially if your country has height limitations for transportation vehicles.
Loading process: Although mechanical detach lowboy equipment trailers are very suitable for loading heavy goods, if you use lifting equipment, ordinary trailers may be the best choice. Most low-bed trailers are loaded from the front or rear.
When you need to remove the gooseneck from the tractor so that the gooseneck remains attached to the mechanical detach lowboy semi trailer frame. Secure the safety hook with a pin to fix the gooseneck in place and prevent the gooseneck from tipping forward.
