57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
Specifications
Brand Name :
BANGYI MACHINERY
Model Number :
57BLY45-124 -PG65
Place of Origin :
China
MOQ :
2pcs
Price :
USD78/PCS
Payment Terms :
T/T, Western Union
Supply Ability :
3000/month
Delivery Time :
20-25 working days
Packaging Details :
carton/ pallets
Voltage :
12VDC
Rated speed :
1950rpm
Torque :
0.035nm
Power :
7.1w
Gear ration :
65:1
Description

Brushless DC Gear Motor 57BLY

General Specifications:
Winding type: star
Hall effect angle: 120° electrical angle
Ambient temperature rage: -20°C~+50°C
Insulation resistance: 100MΩ Min. 500v DC
Dielectric strength: 500v AC 1 minute


Motor Specifications:

Model Unit 57BLY3A45-1224-PG65
Rated voltage V 12
Rated out power W 7.1
Rated speed rpm 1950
Rated current A 2.4
Rated torque N.m 0.035
Peak current A 7.2
Peak torque N.m 0.1
.105Voltage constant V/ Krpm 5
Winding class B
Motor Length mm 45
Remark:
1.We can produce motor according to customer's requirements.

2.Motor can add gearbox and encoder.

57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor57bly45 12VDC 1950rpm 7.1W 65: 1 low voltage Planetary BLDC Gear Motor
