80zyt180 24V 1.7nm 470W Low Voltage high speed brushed DC Motor for Pump
80zyt180 24V 1.7nm 470W Low Voltage high speed brushed DC Motor for Pump
80zyt180 24V 1.7nm 470W Low Voltage high speed brushed DC Motor for Pump
80zyt180 24V 1.7nm 470W Low Voltage high speed brushed DC Motor for Pump
Specifications
Brand Name :
BANGYI MACHINERY
Model Number :
80ZYT180-236
Place of Origin :
China
MOQ :
2pcs
Price :
USD85/PCS
Payment Terms :
T/T, Western Union
Supply Ability :
1000/month
Delivery Time :
20-25 working days
Packaging Details :
carton/ pallet
Model :
80ZYT180-236
Voltage :
24VDC
Speed :
2600rpm
Torque :
1.7NM
Power :
470W
Colour :
black
Description

PMDC MOTOR 80ZYT Series

General Specifications:
Magnet: Ferrite
Insulation class: B 130°C / F155°C
Temperature rise: 75k Max
Environment temperature and humidit: +15°C ~ +35°C, 45%~ 75%
Protection & cooling: IP40& IC00
Installation: IM B14
Shafts OD: Φ13 Max
Bearing: Ball

Winding:
Voltage: 12~220VDC
Speed:900~7000rpm
Power: 80~450w



Motor Specifications:

Model Voltage
(V DC)		 No Load Rated Load
POWER
(W)		 Length(mm)
Current
(A)		 Speed
(rmin)		 Torque
(N.m)		 Current
(A)		 Speed
(r/min)

80ZYT180-236
 24 1.5 3600 1.7 32 2600 470 180
Remark:
1.We can produce motor according to customer's requirements.
2.Motor can add gearbox and encoder.
