Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator
Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator
Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator
Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator
Specifications
Place of Origin :
China
Brand Name :
Peony
Certification :
ISO9001&ISO14001,CE
Model Number :
PDSS20-30
MOQ :
1
Packaging Details :
Standard export packing
Delivery Time :
45days
Payment Terms :
TT, LC
Supply Ability :
100sets per month
Machine type :
Stainless Steel Starch Separator
Automatic degree :
Fully automatic
Phase :
2 phase
Discharge :
nozzle discharge, full discharge
Separation :
Solid-liquid separation
Product type :
Separation equipment
Function :
starch concentrate
Bearing :
SKF
Bowl material :
SS
Warranty :
12 months
Description

Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator


Description

Starch, including wheat starch, corn starch,cassava starch, potato starch, for example, wheat starch needs the disc separators to help the process to separate starch A,starch B and gluten whatever use traditional Martines or 3phase tricanter process, as corn starch as said, it needs disc separator to exact it into the requested Baumé degree. Peony disc separators have various kinds of models to work in such starch separation and extraction stage. Plant starch has been used as a source of raw material for high-quality starch. Today, consumption of fresh water and energy play a more important role in starch applications.

Competitive Advantages

  • Food hygiene
  • MOC:Stainless steel
  • complied with JB/T6419 "Disc StarchSeparator
  • Continuous operation

Working Principle

PDSS type separator is mainly consists the feed device, rotating drum, cover, the body,horizontal shaft, vertical shaft, ground water pump, machine base, motor and other components.

When the rotating drum running a high speed, when the material enter into the disc separation area through the feeding pump (1), under the action of the centrifugal force field, the starch particles slip to the inside wall of the drum, discharged from the nozzle(2),and the light phase like protein and others will collect to the drum center, discharged out of the machine via centripetal pump(3).The machine has a washing bottom pump, the washing water into the drum from the vertical center hole(4), it is used for washing the yellow paste of the starch material, and effectively improve the quality of starch.

Specification

Capacity

L/h

20000-30000

Motor power

Kw

30

Discharging type

Nozzle continually discharging

Output pressure of clear liquid

Mpa

≤ 0.2

Net weight

Kgs

2150

Dimension

(L × W × H) (mm)

1720 × 1520 × 1760

Note: The rated capacity is the capacity when starch paste concentration is 5-7°Be’.

Wheat starch process chart


Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator

In the flow chart, the 3 phase decanter is mainly used for separate starch A, B starch gluten and gluten. At present, this 3 phase decanter is mainly produced by FLOTTWEG/WESTFALIA and other foreign centrifuge manufacturers.

On this wheat starch production line, we can supply the wheat starch "B" concentration and dewatering equipment-Disc separator and decanter centrifuge

Wheat starch“B”waste :1.5-3Be‘

After the nozzle separator treatment, the underflow concentration is 3-10 Be‘

after concentration and dewatering, the solid content is about 45%.

Specification

  • Application:
  • wheat starch,
  • cornstarch,
  • sweet potato starch,
  • cassava starch
  • potato starch,
  • bleaching earth
  • recovering pulp


More pictures

Cassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch SeparatorCassava Corn Wheat Starch Stack Separator - Centrifuge / Stainless Steel Starch Separator

Guarantee

Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.
We are committed to reward you with a better quality in return for our interest in and faith toward.
We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
