SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
Specifications
Place of Origin :
China
Brand Name :
Peony
Certification :
ISO9001& ISO14001
Model Number :
PDC,PNX
MOQ :
1
Packaging Details :
Standard wooden case
Delivery Time :
60-75days
Payment Terms :
T/T, L/C
Supply Ability :
60sets per month
Electrical components :
Famous
Structure :
NX
MOC :
SS304, SS316
Speed :
Inverter control
Bearing :
SKF
Discharging type :
Partial discharge, self-cleaning
Technical service :
All life free charge
Standard :
GB
Operation :
Continuous
Separation phase :
3 phase
Description

SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge

Brief Introduction

Peony decanter centrifuge is the mechanical equipment used for continuously separating the materials in the suspension with density difference, by the principle of centrifugal setting.

Basic principle

The drum and the spiral feeder rotate in the same direction but with a certain speed difference; the material is led into the feeding spiral inner cylinder via the feeding pipe and, after speeding up, enters the drum; under the action of the centrifugal force field, the relatively heavier solid-phase material deposits on the drum wall forming the residue layer; the solid-phase residue is continuous feeding, separating, dehydrating and discharging under full-speed running.

Features

  • compact structure
  • continuous operation
  • smooth running
  • strong adaptability to the separation material
  • large handling capacity
  • convenient maintenance

Specifications

Model

Diameter

(mm)

Bowl speed

(rpm)

Length

(mm)

G-force

Capacity

(m3/h)

Main motor

power (kw)

Assistant motor

power (kw)

Weight

(kg)

Overall size

(L × W × H) (mm)

PDCS-17

420

3300

1680

2550

5~20

30

11

3610

3331 × 990 × 1066

PDCS-18

450

3300

2000

2739

4~50

30

11

3655

4000 × 1120 × 1239

PDCS-20

500

3200

2000

2860

5~45

55

11

4213

4489 × 1160 × 1350

PDCS-21

540

2800

2000

2366

5~50

45

15

5290

4587 × 1285 × 1368

PS: The above parameters will be subject to the final technical agreement.

Competitive Advantages

  • MOC Stainless Steel ,to meet GMP grade
  • Big capacity
  • Corrosion resistant an resistant key parts
  • Flexible drive and speed adjust mode
  • Famous and reliable electrical components
  • Process of the fish oil and fishmeal flow chart

Pictures:

SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge

Processing equipment

SS316L Material 3 Phase Fish Oil Fish Meal Separation Decanter Centrifuge Machine Tricanter Centrifuge
