Solid - Liquid Automatic Mineral Centrifugal Oil Separator Model 1500L / h

Description

1.Model PDSD1500-M-B1207 separator modular is mainly used to remove water and mechanical impurities from diesel oil, lubricating oil and other mineral oil in marine diesel engine unit and land-used diesel generator unit of power station so as to reduce wear of the diesel engine and other machine, and prolong engine life.

The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.

2.The machine has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.

3.The clear oil and dirty water are let out freely, the sludge is discharged manually.

4.The machine is one kind of rotary machine with high speed, After accurate dynamic balancing, it can run for long time with low vibration, safety and security.

5.The design, product and acceptance are conformed to the standard of GB/T5745 “Marine Disc Separator”.

Advantages

1. Manual type slag removal unit

2. modular design

3. automatic control

Condition for mineral oil separation and actual capacity (refer to the chart)

Main Technical Specification

Automatic Control System

The whole unit consists of

1. Separator 2. Steam heater 3. Electric control box 4. Oil filter 5. Temperature adjust valve

6. Pressure gauge 7. Vacuum gauge 8. Pressure switch 9. Brass filter ball valve

10. Manual three-way valve 11. Stop-check valve 12. High temperature ball valve

13. Draining valve 14. Ball valve 15. Skid

Value Analysis

1. According to the requirements of each classification society, all modules are equipped with oil leak alarm and high temperature alarm.

2. Oil.hydraulic,pneumatic control part adopts the Brand Baode (Germany).

3. Heater adopts brand SWEP (Germany).

4. Pressure control adopts Korean products or products

5. Screw pump is used instead of gear pump.

6. All equipped with automatic temperature control device (Made by the RTK production in Germany or made in China)

7. The main electrical components of standard electrical control box are produced by Schneider company while PLC is produced by Siemens or Mitsubishi.

8. The complete sets referred above are all Peony’s production of automatic Standard Controls and we certainly can modify the configuration list according to customers’ specified requirements.

Aspect of the unit:

Pictures

Guarantee

Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.We are committed to reward you with a better quality in return for our interest in and faith toward.We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
