Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Specifications
Brand Name :
Peony
Model Number :
BB-200
Certification :
ISO
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1Set
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
60 Set/Sets per Month
Delivery Time :
1-10sets/45days ＞10sets/To be negotiated
Packaging Details :
Wooden case
Condition :
New
Type :
Basket Centrifuge
Power(W) :
3.7~11kw
Grade :
GMP
MOC :
SS304,316 as option
Motor :
Explosion Proof
Equipped :
Inverter and PLC
Voltage :
220V,380V,440V,480V...
Description
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Product Description
BB series centrifuge batch operation extraction equipment, the solid is discharged from top, and liquid is drained at lower part of the machine.
The dry material is put into the bag inside the centrifuge basket, feed in cold ethanol, flood by two directions of rotating, and then use spin for dewatering, and get the mixture of ethanol and CBD oil. The working temperature is very low, around -40~-80℃, to prevent the ethanol from volatilization.
Advantages
Model BB flat-plate centrifuge has got rid of traditional hanging type of leg support and instead it adopts flat-plate counterweight and high-viscosity damping vibration reducer for absorbing vibration.
The installation requires no foundation.
Working Steps

▷System loading

▷Program Menu
▷Fill
▷The Wash cycle
▷System Draining
▷Spin Dry Cycle
▷System Unloading
▷Repeat Process


Application
1.Plant oil extraction
2. oil extraction
3.Trim extraction
4.Any dry biomass extraction

Technical parameters

Type Basket

Motor

(kw)

(UL Listed/Optional)

Overall size

(L × W × H)

(mm)

Diameter

(mm)

Volume

(L)

 dry plant (lbs)
BB-200 1200 700 200/batch 11 2000x1620x1570


Pictures
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation

Service
★ 12 months guarantee period from machine arriving date.
☆ Abundant spare parts in stock are available to provide.
★ Our technicians could be dispatched for overseas service.
☆ 7*24 hours technical consultation.
★ Your workers could get trained both in our factory and yours.
☆ Routine tracing till the machine work properly will be done timely.
★ We will remind you to do the normal maintenance.
☆ Your suggestions or any comments & reflection would be treated in priority.
★ Marketing team will visit you during our visit in your country if you require.




“Star Level”:
Cold Solvent Extract Basket Centrifuge Machine For Solid Liquid Separation
