Technical specification | Z1 G9 Tower Desktop |
Processor family | 10th Generation Intel® Core™ i5 i7 i9 processor 11th Generation Intel® Core™ i5 i7 i9 processor Intel® Xeon® W- 1300 series |
Chipset | Intel® W580 |
Memory | up to 128GB |
Memory Slots | 4 DIMM |
Internal Storage | SATA Hard Disk Drive (HDD) (8.89 cm (3.5 in)):500 GB SATA 7200 rpm Hard Disk Drive 1 TB SATA 7200 rpm Hard Disk Drive 2 TB SATA 7200 rpm Hard Disk Drive 1 TB SATA 7200 rpm Hard Disk Drive (Enterprise Class) 2 TB SATA 7200 rpm Hard Disk Drive (Enterprise Class) 4 TB SATA 7200 rpm Hard Disk Drive (Enterprise Class) 8 TB SATA 7200 rpm Hard Disk Drive (Enterprise Class) 500 GB SATA 7200 rpm SED TWR Hard Disk Drive Solid state drives (SSD) HP ZTurbo 1 TB PCIe Gen 4 x4 TLC Z2 G8 TWR/SFF SSD HP ZTurbo 256 GB PCIe Gen 4 x4 SED Z2 G8 TWR/SFF SSD HP ZTurbo 256 GB PCIe Gen 4 x4 TLC Z2 G8 TWR/SFF SSD HP ZTurbo 2 TB PCIe Gen 4 x4 TLC Z2 G8 TWR/SFF SSD HP ZTurbo 512 GB PCIe Gen 4 x4 SED Z2 G8 TWR/SFF SSD HP ZTurbo 512 GB PCIe Gen 4 x4 TLC Z2 G8 TWR/SFF SSD Z Turbo 1 TB 2280 PCIe Gen 4 x4 Self Encrypted OPAL2 TLC M.2 Z2 SSD Z Turbo 2 TB 2280 PCIe Gen 4 x4 Self Encrypted OPAL2 TLC M.2 Z2 SSD |
Graphics | Integrated Intel UHD Graphics 750 and Intel UHD Graphics 730 Entry 3D NVIDIA Quadro P400 2 GB Graphics Mid-range 3D AMD Radeon ProWX 3200 4 GB Graphics NVIDIA Quadro T1000 4 GB Graphics Ultra High-End 3D NVIDIA Quadro RTX 3000 6 GB Graphics Graphics cable adapters HP DisplayPort to H MI True 4k Adapter HP Single miniDP-to-DP Adapter Cable HP DisplayPort to DVI-D Adapter HP DisplayPort to VGA Adapter HP USB Type-C to DisplayPort Adapter HP USB Type-C to H MI Adapter HP USB Type-C to VGA Adapter |
Ports | 2 SuperSpeed USB Type-A 10Gbps signaling rate; 1 universal audio jack; 2 SuperSpeed Type-A USB 5Gbps signaling rate (1 charging) |
Expansion slots | 1 PCIe 3 x4 (x16 connector); 1 PCIe 3 x4 (x4 connector); 1 M.2 2230 PCIe 3 x1; 1 M.2 2280 PCIe 4 x4; 1 M.2 2280 PCIe 3 x4; 1 PCIe 3 x1 (x4 connector); 1 PCIe 4 x16 (x16 connector) (1 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage) |
Ports | 1 audio-in; 1 audio-out; 1 RJ-45; 2 DisplayPort™ 1.4; 2 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 5Gbps signaling rate; 3 USB Type-A 480Mbps signaling rate |
