Specifications
Brand Name :
Lenovo
Model Number :
DB630S
Place of Origin :
China
MOQ :
1 pieces
Price :
$10,000.00 - $20,000.00/pieces
Payment Terms :
T/T
Supply Ability :
100 Piece/Pieces per Month
Delivery Time :
1-2months
Packaging Details :
Carton Packing
Product Category :
Switch
Model :
DB630S
Products Status :
Stock
Ports :
≥ 48
Form factor :
Standalone or 2U rack mount
Port :
Shenzhen/Beijing
Description
Details Images
Lenovo ThinkSystem DB630S For Standalone Or 2U Rack Mount 32Gb FC SAN Switch
Form factor
Standalone or 2U rack mount
Ports
* 96x SFP+ ports:
* Model CTO5: 48 ports activated and 48x 32 Gb FC SWL SFP+ transceivers included; up to two optional 24-port activation
licenses or bundles (24-port licenses and 24x 32 Gb FC SWL SFP+ transceivers)
* Model CTO6: 96 ports activated and 96x 32 Gb FC SWL SFP+ transceivers included

* 8x QSFP+ ports (require an optional activation license or bundle [32-port license pack and 8x 128 Gb FC SWL SFP+ V2
transceivers])
Media types
* 128 Gb (4x 32 Gb) FC QSFP+: short wavelength (SWL), long wavelength (LWL)
* 4x 16 Gb FC QSFP+: SWL
* 32 Gb FC SFP+: SWL, LWL, extended long wavelength (ELWL)
* 16 Gb FC SFP+: SWL, LWL, extended long wavelength (ELWL)
* 10 Gb FC SFP+: SWL, LWL
Port speeds
* 128 Gb (4x 32 Gb) FC SWL QSFP+: 128 Gbps, 4x 32 Gbps, or 4x 16 Gbps
* 128 Gb (4x 32 Gb) FC LWL QSFP+: 128 Gbps or 4x 32 Gbps fixed
* 4x 16 Gb FC QSFP+: 4x 16/8/4 Gbps auto-sensing
* 32 Gb FC SFP+: 32/16/8 Gbps auto-sensing
* 16 Gb FC SFP+: 16/8/4 Gbps auto-sensing
* 10 Gb FC SFP+: 10 Gbps fixed
FC port types
F_Port, E_Port, EX_Port (Requires an optional Integrated Routing License), M_Port (Mirror Port), D_Port (Diagnostic Port)
Dimensions
Height: 87 mm (3.4 in.); width: 440 mm (17.3 in.); depth: 610 mm (24.0 in.)
Weight
Empty: 19.05 kg (42.0 lb.); Fully configured: 21.3 kg (47.0 lb.)
