ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF
Specifications
Brand Name :
abb
Model Number :
3BSE008510R1
Place of Origin :
USA
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
1
Delivery Time :
5-8 work daysRockwell Automation
Packaging Details :
New in original boxRockwell Automation
Condition :
new
Voltage :
50 V
Channels :
16
warranty :
1 year
Type :
Digital Output
Signal specification :
24V d.c. (12 - 32 V d.c.), 0.5 A
Mechanics :
S800L
Global Commercial Alias :
3BSE008510R1
Description

ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF

Product information ABB 3BSE008510R1 :

  • Manufacturer: ABB

  • Product no : 3BSE008510R1

  • Product type : DO810 Digital Output

  • I/O Voltage, DC: 24 V d.c.

  • Number of Output Channels: 16

  • I/O Current, DC : 500 mA

  • Product Net Height: 7.5 cm
    Product Net Length: 15 cm
    Product Net Width: 15 cm

This module has 16 digital outputs. The output voltage range is 10 to 30 volt and the maximum continuous output current is 0.5 A. The outputs are protected against short circuits, over voltage and over temperature.

The outputs are divided into two individually isolated groups with eight output channels and one voltage supervision input in each group. Each output channel consists of a short circuit and over temperature protected high side driver, EMC protection components, inductive load suppression, output state indication LED and optical isolation barrier.

The process voltage supervision input give channel error signals if the voltage disappears. The error signal can be read through the ModuleBus. The outputs are current limited and protected against over temperature. If the outputs are overloaded the output current will be limited.


More information about 3BSE008510R1 :

  • 16 channels for 24 V d.c. current sourcing outputs
  • 2 isolated groups of 8 channels with process voltage supervision
  • Output status indicators
  • OSP sets outputs to predetermined state upon error detection
  • Short-circuit protection to ground and 30 V
  • Over-voltage and over-temperature protection
Model Mechanics Type
AI801 S800L Analog Input
AI810 S800 Analog Input
AI815 S800 Analog Input
AI820 S800 Analog Input
AI825 S800 Analog Input
AI830A S800 Analog Input
AI835A S800 Analog Input
AI843 S800 Analog Input
AI845 S800 Analog Input
AI880A S800 Analog Input
A1890 S800 Analog Input
AI893 S800 Analog Input
AI895 S800 Analog Input
AO801 S800L Analog Input
AO810V2 S800 Analog Output
AO815 S800 Analog Output
AO820 S800 Analog Output
AO845A S800 Analog Output
AO890 S800 Analog Output
AO895 S800 Analog Output


3BSE008510R1 's details:


ABB 3BSE008510R1 DIGITAL OUTPUT MODULE 0.5 AMP 24 VDC 16 CHANNEL SHORT CIRCUIT PROOF

Extend :

TU814V1(3BSE013233R1):16 channels for 24 V d.c. inputs with current sourcing​ 2 Isolated groups of 8 with voltage supervision
Note: Use with I/O → AI810, AI815, AI820, AI830, AI835A, AI835, AI845, AO810, AO810V2, AO815, AO820, AO845, AO845A, DI810, DI811, DI814, DI830, DI831, DI840, DI880, DI885, DO810, DO814, DO815, DO840, DO880, DP820 and DP840.

TU850 (3BSE050930R1) : Complete 2-wire connections for up to 16 channels.
Note: 40 up to 16 I/O channels , 16 current limited sensor/transmitter power outlets, D-sub connectors 25 pin (male).

TU838 ( 3BSE008572R1) : Complete installation of I/O modules using 3-wire connections,fuses and field power distribution.
Note: 40 , up to 16 I/O channels, 8 fused sensor power outlets, 4 Process power, 12 Process power.
