Emerson Rosemount 8800DW005 Wafer Vortex Flow Meter, 0.5 Inch (DN15)
Emerson Rosemount 8800DW005 Wafer Vortex Flow Meter, 0.5 Inch (DN15)
Emerson Rosemount 8800DW005 Wafer Vortex Flow Meter, 0.5 Inch (DN15)
Emerson Rosemount 8800DW005 Wafer Vortex Flow Meter, 0.5 Inch (DN15)
Specifications
Brand Name :
Rosemount
Model Number :
Rosemount 8800DW005
Certification :
CE, ect
Place of Origin :
USA
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
In Stock
Delivery Time :
3-5days
Packaging Details :
New Original Box
Description

Rosemount 8800DW005 Wafer Vortex Flow Meter, 0.5 Inch (DN15

Product Description

Flangeless meter body offers a cost-effective, lightweight alternative to flanged Vortex flow meters. A compact, space-saving design provides versatility in any location.

Specifications
Flow Meter Accuracy± 0.70% of mass flow rate in water using 8800 MultiVariable (MTA/MCA option)
± 2% of mass flow in steam using 8800 MultiVariable (MTA/MCA option)
± 1.3% of rate at 30 psia through 2,000 psia in steam using 8800 MultiVariable (MPA option)
± 1.2% of rate at 150 psia in steam using 8800 MultiVariable (MCA option)
± 1.3% of rate at 300 psia in steam using 8800 MultiVariable (MCA option)
± 1.6% of rate at 800 psia in steam using 8800 MultiVariable (MCA option)
± 2.5% of rate at 2,000 psia in steam using 8800 MultiVariable (MCA option)
± 0.65% of volumetric rate for liquids (uncompensated)
± 1% of volumetric rate for gas and steam (uncompensated)
Turndown38:1
Output4-20 mA with HART® 5 or 7
4-20 mA with HART® 5 or 7 and scalable pulse output
FOUNDATION fieldbus ITK6 with 2 Analog Input blocks, 1 Backup Link Active Scheduler function block, 1 Integrator function block, and 1 PID function block
Modbus RS-485 with device status and 4 variables
Wetted MaterialStainless Steel; 316 / 316L and CF3M
Nickel Alloy; C-22 and CW2M
High Temp Carbon Steel; A105 and WCB
Low Temp Carbon Steel; LF2 and LCC
Duplex; UNS S32760 and 6A
Consult factory for other wetted material
Flange OptionsANSI Class 150 to 1500
DIN PN 10 to PN 160
JIS 10K to 40K
Flanges are available in a variety of facings
Consult factory for additional flange ratings
Operating Temperatures-330°F to 800°F (-200°C to 427°C)
Line Size1/2" - 8" (15 - 200 mm)

Features
An isolated sensor allows for inline replacement without breaking the process seal
Increase plant availability and eliminate potential leak points with a unique gasket-free meter body design
Eliminate downtime and maintenance costs associated with plugged impulse lines with a non-clog meter body design
Achieve vibration immunity with a mass balanced sensor and Adaptive Digital Signal Processing with visual filtering
A standard internal signal generator included in every meter simplifies electronics verification
All meters arrive pre-configured and hydrostatically tested, making them ready and easy to install
Simplify SIS compliance with available dual and quad Vortex flow meters
Detect liquid to gas phase change using Smart Fluid Diagnostics
