4040 8040 Stainless Steel High Pressure Vessel FRP RO Membrane Housing
4040 8040 Stainless Steel High Pressure Vessel FRP RO Membrane Housing
Specifications
Brand Name :
AJIEWATER
Model Number :
4040 or 8040
Certification :
CE;ISO
Place of Origin :
Guangzhou-China
MOQ :
1 unit
Price :
Negotiable
Supply Ability :
1000 unit per month
Delivery Time :
7-15 working days
Packaging Details :
In wooden case or protection warp carton.
Payment Terms :
Cash,PayPal, T/T, L/C, Western Union
Warranty :
2 Year
Color :
White,Transparent
Size :
25*12mm
Function :
remove salt and other harm substance
Weight :
5KG/CBM,1g
Working temperature :
Less than 45C
Cas no. :
112926-00-8
Working pressure :
150PSI/100PSI
Description

High Pressure Vessel FRP RO Membrane Housing 4040/8040 Stainless Steel High Pressure Vessel FRP RO Membrane Housing 4040

Features

1000 PSI Maximum Pressure

End-Entry

Available for membrane elements in 14”, 21” and 40” lengths

Materials: Strong coated FRP/fiberglass and feature machined, duplex end caps for extended life under corrosive conditions.

Stainless Steel End Plate, Securing Ring, Locking Kit and Screws.

For Direct Connection to CHUNKE / FilmTec style membranes

Easy to install and maintain

Detailed Product Description

Place Of Origin:

 Guangzhou, China

Membrane Size:

 4040 / 8040

Working Temperature:

 -7 - 49C

Material:

 FRP Composite

Working Pressure:

 300 - 1000 Psia

Connection:

 End / Side

Color:

 White Color

Application:

 RO System

Name:

 High Quality 4040/8040 Stainless Steel /FRP RO Membrane Pressure Vessel Housing For RO Water Treatment Plant

High Quality 4040/8040 Stainless Steel /FRP RO Membrane Pressure Vessel Housing for RO Water Treatment Plant

ajiewater fiberglass housings are suitable for seawater conditions, rated at 1000 psi. The vessels use a strong coated fiberglass and feature machined, duplex end caps for extended life under corrosive conditions. The end caps are designed for direct connection to Applied Membranes and FilmTec/DOW 2.5” standard, male style elements.

Benefits

  • Strong coated FRP/fiberglass and feature machined, duplex end caps for extended life under corrosive conditions

  • Stainless Steel End Plate, Securing Ring, Locking Kit and Screws

  • Suitable for corrosive seawater conditions

  • Designed for ease of installation and maintenance

  • Ideal for operating pressures up to 1,000 PSI

  • CHUNKE has been manufacturing Water Filtration Components for over 10 years

  • CHUNKE Products have earned an industry-wide reputation for their high quality and superior performance

  • Individually inspected

Model

Pressure,

psi

Connection

Membrane Size

Working Temperature

CK-4040-(1-4W)-300

300

Side

4040

-7oC to 49oC

CK-4040-(1-4W)-450

450

Side

4040

-7oC to 49oC

CK-4040-(1-4W)-600

600

Side

4040

-7oC to 49oC

CK-4040-(1-4W)-800

800

Side

4040

-7oC to 49oC

CK-4040-(1-4W)-1000

1000

Side

4040

-7oC to 49oC

Model

Pressure,

psi

Connection

Membrane Size

Working Temperature

CK-4040-(1-7W)-150

150

Side

8040

-7oC to 49oC

CK-4040-(1-7W)-300

300

Side

8040

-7oC to 49oC

CK-4040-(1-7W)-450

450

Side

8040

-7oC to 49oC

CK-4040-(1-7W)-800

800

Side

8040

-7oC to 49oC

CK-4040-(1-7W)-1000

1000

Side

8040

-7oC to 49oC

4040 8040 Stainless Steel High Pressure Vessel FRP RO Membrane Housing
