Large Scale UV water disinfection system Water Treatment Plant Accessories
Large Scale UV water disinfection system Water Treatment Plant Accessories
Specifications
Brand Name :
AJIEWATER
Model Number :
CK-UV
Place of Origin :
Guangzhou
MOQ :
1 unit
Supply Ability :
1000 unit per month
Delivery Time :
7-15 working days
Packaging Details :
In wooden case or protection warp carton
Certification :
CE,ISO
Price :
negotiation
Payment Terms :
L/C, MoneyGram
Material :
Fiber glass
Application :
Filtration
Type :
Water Filter Parts
Product name :
Teenwin MBR wastewater treatment plant
Usage :
Coating Auxiliary Agents
Capacity :
1000L/H
Warranty :
1 Year
Color :
Blue / Nature / Grey or Custom
Description

Large Scale / Big Size UV Sterilizer for RO Water Treatment Plant

A UV sterilizer is used to control infections by stopping the spread of microorganisms from fish/coral/invertebrate to another through the water. It is also used in pond applications to control free-floating algae. When operated correctly, free-floating microorganisms will be killed by the UV light. Note that the organisms must be in the water that flows to the UV sterilizer. The UV light has no residual effect and will not kill organisms attached to fish or rocks (e.g., algae).

Place Of Origin

Guangzhou

Flow Rate

10T To 200T

Max. Operating Pressure

0.8MPa

Material

SS304 , SS316

Dimension

Changable

Customization

Available

Color

Metallic Surface

Application

Killing Bacteria

Name

Large Scale / Big Size UV Sterilizer For RO Water Treatment Plant

Power

160W To 2500W

Working principle


The UV sterilizer utilizes a germicidal fluorescent lamp that produces light at a wavelength of approximately 254 nanometers (2537 Angstroms). The water with the bacteria/algae passes over the bulb (or around the bulb if a quartz sleeve is used) and is irradiated with this wavelength. As the light penetrates the bacteria/algae, it mutates the DNA (genetic material), preventing growth/multiplication of the organism.


Application scope of ultraviolet sterilizer

1. Food factory, Cosmetic factory disinfection
2. Registries, Cold storage sterilization
3. Canteen, School, Hospital, Hotel and Restaurant
4. Swimming pool sterilization and disinfection
5. Beverage and Drinking water disinfection

Limitation of Use


The UV water disinfection system NOT intended for the treatment of water that has an obvious contamination or intentional source, such as raw sewage, nor is the unit intended to convert wastewater to microbiologically safe drinking water.

Model

Flow

Power

Peaction Chamber Size

Electric cabinet box size

Inlet/ Outlet size

Max Operation Pressure

CK-UV60T

60T/H

150W*5

L1700*W280*H490mm

L700*W550*H200mm

4"

0.8Mpa

CK-UV70T

70T/H

150W*6

L1700*W280*H490mm

L700*W620*H200mm

5"

0.8Mpa

CK-UV80T

80T/H

150W*7

L1700*W280*H490mm

L800*W680*H200mm

5"

0.8Mpa

CK-UV100T

100T/H

150W*8

L1700*W355*H545mm

L800*W680*H200mm

6"

0.8Mpa

CK-UV125T

125T/H

150W*10

L1700*W355*H545mm

L1150*W570*H200mm

6"

0.8Mpa

CK-UV150T

150T/H

150W*12

L1700*W385*H595mm

L1150*W650*H200mm

8"

0.8Mpa

CK-UV200T

200T/H

150W*16

L1700*W385*H595mm

L1200*W800*H200mm

8"

0.8Mpa

Large Scale UV water disinfection system Water Treatment Plant Accessories
