250 LPH Heat Disinfection Ultrapure RO EDI Water Treatment System For Medical
250 LPH Heat Disinfection Ultrapure RO EDI Water Treatment System For Medical
Specifications
Brand Name :
AJIEWATER
Model Number :
AJRO-250LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 unit per month
Delivery Time :
7-10 days
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Desalination Rate :
>=97%
Electrical Power :
110V
Color :
white
Pretreatment Valve :
Automatic Control Valve
Recovery rate :
50％-75％
Features :
Water purifier/water treatment
Pipe fittings :
SUS304 / U-PVC
Application :
FRP
Description
250 LPH Heat Disinfection Ultrapure RO EDI System For Medical​
Detailed Product Description
Items: 250LPH Heat Disinfection Machine Ultrapure RO EDI System Production Capacity: 250liters Per Hour
Recovery Rate: 50%-75% Electrical Power: 220/380V 50/60Hz
Tank Material: FRP/ Stainless Steel/ Carbon Steel Control Valve: Automatic/ Manual
Pipe Fitting: SUS304/ U-PVC Warranty: 1 Year
Size: 1550*620*1670MM Weight: 200KG
Feed Water TDS: <2000mg/L Desalination Rate: >=97%
High Light:

Ultrapure RO EDI System

,

FRP RO EDI System

,

250LPH Heat Disinfection Machine

RO EDI water treatment system is developed a membrane separation technology, which mainly use the semipermeable membrane permeation principle, to give it a certain way by applying a pressure on the natural infiltration direction against the force of the water in the concentrated solution dilute the solution to penetrate this way is called reverse osmosis. By the components of the device is reverse osmosis reverse osmosis unit.

EDI details

China brand and Europe/USA brand for optional.

EDI, also called electric desalination is a new ultra pure water technology which gradually developed in the 20th century, which combines electric dialysis technology and ions exchange technology.

It is using the selectivity penerate function of anion and cation membrane and exchange function of ions exchange resin, under direct current electric field to make ion directed migration.

Finally to make deep desalination of water. In the same time, hydrogen ion and hydroxide ion which produced when water ionized will regeneration, and it can produce ultra pure water continuously.

Features

This system occupy little space, easy to operate, wide application range.
Reverse osmosis desalting rate ≥99%, machine desalting rate ≥97%. 98% of organic matters, colloids and bacteria can be removed.
Finished water under good electric conductivity, 1st stage ≤10μs/cm, 2nd stage around 2-3μs/cm, EDI≤0.2μS/cm(based on raw water≤300μs/cm).

Processing: Raw water tank(user supply)→ raw water pump→quartz sand filter →activated carbon filter→security filter→1st stage high pressure pump→1st stage ro system→2nd stage high pressure pump→2nd stage ro system→pure water tank(user supply)+UV sterilizer+precision filter+ water supply point

Main parts function:
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Quartz sand filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect.
3. Activated Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump-- Provide the high pressure to RO membrane ro.
7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.
