Cisco SFP-10G-LR Compatible SFP+ Transceiver (SMF, 1310nm, 10km, DOM, LC)
Cisco SFP-10G-LR Compatible SFP+ Transceiver (SMF, 1310nm, 10km, DOM, LC)
Specifications
Brand Name :
OLKOPTO
Model Number :
OLSP311XL-CD10
Certification :
CE, RoHS, FCC, FDA, UL, EMC, ISO9001
Place of Origin :
China
MOQ :
1 pc
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
80-120k per month
Delivery Time :
3-6 working days
Packaging Details :
10pcs/ foil bag
Product Name :
10G SFP+ 1310nm 10km
Data Rate :
10-Gigabit
Form Factor :
SFP+
Wavelength :
1310nm
Distance :
10km
Compatibility :
Cisco
TX Power :
-6 ~ 0 dBm
Receiver Sensitivity :
< -14.4 dBm
Function Options :
DOM
Operating Temperature :
0-70°C, -40-85°C
Description

Cisco SFP-10G-LR Compatible SFP+ Transceiver (SMF, 1310nm, 10km, DOM, LC)

Product Features

1. Hot pluggable
2. 10Gb/s serial optical interface
3. Up to 10km on SMF
4. SFP MSA package with duplex LC connector
5. Digital Diagnostic Monitor Interface
6. Very low EMI and excellent ESD protection
7. High transmission margin
8. +3.3V single power supply
9. CISCO and main brands coding available

Electrical Characteristics (TOP(C) = 0 to 70 ℃, TOP(I) =-40 to 85 ℃,VCC = 3.13 to 3.47 V)

Parameter Symbol Min. Typ Max. Unit Note
Transmitter
Differential data input swing VINPP 180 700 mVpp 1
Transmit Disable Voltage VD VCC-0.8 Vcc V
Transmit Enable Voltage VEN Vee Vee+0.8
Input differential impedance Rin 100 Ω
Receiver
Differential data output swing Vout,pp 300 850 mVpp 2
Output rise time and fall time Tr, Tf 28 Ps 3
LOS asserted VLOS_F VCC-0.8 Vcc V 4
LOS de-asserted VLOS_N Vee Vee+0.8 V 4

Note:

1. Connected directly to TX data input pins. AC coupling from pins into laser driver IC.

2. Into 100Ω differential termination.

3. 20 – 80%. Measured with Module Compliance Test Board and OMA test pattern. Use of four 1’s and four 0’s sequence in the PRBS 9 is an acceptable alternative.

4. LOS is an open collector output. Should be pulled up with 4.7kΩ – 10kΩ on the host board. Normal operation is logic 0; loss of signal is logic 1.

Optical Characteristics (TOP(C) = 0 to 70 ℃, TOP(I) =-40 to 85 ℃,VCC = 3.13 to 3.47 V)

Parameter Symbol Min. Typ Max. Unit Note
Transmitter
Operating Wavelength λ 1260 1310 1355 nm
Ave. output power (Enabled) PAVE -6 0 dBm 1
Side-Mode Suppression Ratio SMSR 30 dB
Extinction Ratio ER 4 4.5 dB
RMS spectral width Δλ 1 nm
Rise/Fall time (20%~80%) Tr/Tf 50 ps
Dispersion penalty TDP 3.2 dB
Relative Intensity Noise RIN -128 dB/Hz
Output Optical Eye Compliant with IEEE 0802.3ae
Receiver
Operating Wavelength 1270 1600 nm
Receiver Sensitivity PSEN2 -14.4 dBm 2
Overload PAVE 0.5 dBm
LOS Assert Pa -30 dBm
LOS De-assert Pd -18 dBm
LOS Hysteresis Pd-Pa 0.5 dB

Notes:

1. Average power figures are informative only, per IEEE 802.3ae.

2. Measured at the BER less than 1E-12, back to back. The measure pattern is PRBS 231-1 with worst ER=4.5@ 10.3125Gb/s.

Product Descriptions

Olinkcom's OLSP311XL-CD10 is designed for 10Gb/s serial optical interfaces for data communications with single mode fiber (SMF) 1310nm. The transceiver can support 1.25 Gb/s to 11.1Gb/s. It is designed to optimize high performance and it is costly effective for customers’ solution in datacom.

Applications

● 10G Base-SR/SW at 10.3125G

● 10G Fiber Channel

● Other optical links

● 10G Ethernet

Compatibility

• Cisco 2360-48TD-S
• Cisco 3100 WS-CBS3110X-S-I
• Cisco 3100 WS-CBS3120X-S
• Cisco 3100 WS-CBS3130X-S
• Cisco 4500 WS-X4013+10GE
• Cisco 4500 WS-X4516-10GE
• Cisco 4500 WS-X45-SUP6-E
• Cisco 4500 WS-X45-SUP6L-E
• Cisco 4500 WS-X45-SUP7-E
• Cisco 4500 WS-X45-SUP7L-E
• Cisco 4500 WS-X45-SUP8-E
• Cisco 4500 WS-X45-SUP8L-E
• Cisco 4500 WS-X4606-X2-E
• Cisco 4500 WS-X4712-SFP+E
• Cisco 4900 ME-4924-10GE
• Cisco 4900 WS-C4928-10GE
• Cisco 4900 WS-C4948-10GE
• Cisco 4900 WS-C4948E

• Cisco Nexus 7000 N7K-F248XP-25E
• Cisco Nexus 7000 N7K-M108X2-12L
• Cisco Nexus 7000 N7K-M132XP-12
• Cisco Nexus 7000 N7K-M132XP-12L
• Cisco Nexus 7000 N7K-M224XP-23L
• Cisco Nexus 9000 N9K-C92160YC-X
• Cisco Nexus 9000 N9K-C9372PX
• Cisco Nexus 9000 N9K-C9372PX
• Cisco Nexus 9000 N9K-C9372PX-E
• Cisco Nexus 9000 N9K-C9372PX-E
• Cisco Nexus 9000 N9K-C9396PX
• Cisco Nexus 9000 N9K-C9396PX
• Cisco Nexus 9000 N9K-X9464PX
• Cisco Nexus 9000 N9K-X9564PX
• Cisco UCSB-5108-AC2
• Cisco UCS-FI-6248UP
• Cisco UCS-FI-6296UP
• Cisco UCS-FI-6324UP
