Passive products 8 Channel CWDM Filters 1470~1610nm
Passive products 8 Channel CWDM Filters 1470~1610nm
Specifications
Brand Name :
GEZHI or OEM
Model Number :
CWDM8CHMD47LPLGX
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Get Latest Price
Payment Terms :
T/T, Paypal,Western Union
Supply Ability :
100000 Channel per month
Delivery Time :
5-8 work days
Packaging Details :
paper box with foam
Product Name :
Passive CWDM
Datarate :
155Mb/s
Wavelength :
1470~1610nm
Distance :
20km
Connector :
LC/UPC
Application :
PON Networks
Description

Passive products 8 Channel CWDM Filters 1470~1610nm

GEZHI Passive products 8 Channel CWDM Filters 1470~1610nm is an excellent choice for increasing bandwidth capacity while keeping costs down. The Passive products 8 Channel CWDM Filters 1470~1610nm, based on standard Thin Film Filter (TFF) technology with a proprietary packaging, offers you smallest component dimensions combined with an outstanding performance and reliability.

Our CWDM MUX DEMUX are perfectly suited to transport PDH, SDH / SONET, ETHERNET services over WWDM, CWDM and DWDM in optical metro edge and access networks.

Features

Applications
  • Low Insertion Loss
  • High Channel Isolation
  • Excellent Thermal Stability
  • High Stability and Reliability
  • Telcordia Compliant
  • RoHS Compliant
  • CWDM systems
  • Metro/Access optical network
  • Bi-direction

Ordering Information

CWDM-X-XX

Configuration Number of Channels 1st Channel Fiber Type Fiber Length In/Out Connector

M=Mux

D=Demux

MD=Mux+Demux

04=4 Channel

08=8 Channel

16=16 Channel

18=18 Channel
N=N Channel

……

27=1270nm
47=1470nm
49=1490nm

……
61=1610nm
SS=special

 1=Bare fiber
2=900um
Loose tube
3=2mm Cable
4=3mm Cable		 1=1m
2=2m
S=Specify

0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=LC/APC

6=LC/PC

……

Specifications

Parameter 4 Channel 8 Channel 18 Channel
Mux Demux Mux Demux Mux Demux
Channel Wavelength (nm) 1270~1610
Center wavelength Accuracy (nm) ±0.5
Channel Spacing (nm) 20
Channel Passband (@-0.5dB bandwidth (nm) >13
Insertion Loss (dB) ≤1.2 ≤2.5 ≤4.2
Channel Uniformity (dB) ≤0.5 ≤1.0 ≤1.5
Channel Ripple (dB) 0.3
Isolation (dB) Adjacent N/A >30 N/A >30 N/A >30
Non-adjacent N/A >40 N/A >40 N/A >40
Inertion Loss Temperature Sensitivity (dB/°C) <0.005
Wavelength Temperature Shifting (nm/°C) <0.002
Polarization Dependent Loss (dB) <0.1
Polarization Mode Dispersion <0.1
Directivity (dB) >50
Return Loss (dB) >45
Maximum Power Handling (mW) 300
Opterating Temperature (°C) -20~+75
Storage Temperature (°C) -40~85
Package dimension (mm) LGX cassette

Above specification are for device with connector.
