Specifications
Brand Name :
GEZHI or OEM
Model Number :
GZ-1x8 PLC Splitter
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
China
MOQ :
1
Price :
Get Latest Price
Supply Ability :
80000pcs per month
Delivery Time :
2~7working days
Packaging Details :
2pcs in a foam with paper Box
Product Name :
Fiber Optical Splitter
Wavelength :
1260~1620nm
Type :
1x8
Package :
Stainless steel Tube
Connector :
SC/APC
Application :
LAN, WAN and Metro Networks
Description
1x8 PLC Fiber Splitter SC/APC Mini module 900um tube 1.5meter FTTH system

Single-Mode G.657A1 fiber, 900μm input/output, 1260-1650nm, fit for outdoor fiber distribution box

1×8 Blockless Fiber PLC Splitter, Singlemode, 900μm Fiber, SC/APC Connector

Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.

Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It's mainly used for various connection and distribution boxes or network cabinets.

Features Application
1×8 blockless PLC Splitter, SC/APC connector Optical Signal Distribution
900μm ITU G.657A1 for fiber input/output Data Communications
Low insertion loss ≤ 10.7dB Lan and CATV System
Low polarization dependent loss (PDL) ≤ 0.3dB FTTX Deployment
Operating bandwidth: 1260 - 1650nm FTTH Network
Compact design, suitable for installation in optical equipments Passive Optical Networks (PON)
Wide Operating Temperature: -40 - 85°C, support industry standard applications Measuring System and Laser System
High reliability and stability, Telecordia GR-1221/1209 compliant DWDM and CWDM Systems

1x8 PLC Splitter with SC/APC ​Specification

Parameters 1×2 1×4 1×8 1×16 1×32 1×64 1×128
Operating Wavelength (nm) 1260～1650
Fiber Type G657A1 or customer specified
Insertion Loss (dB)(P/S Grade) 3.8/4.0 7.2/7.4 10.3/10.7 13.5/13.7 16.5/16.9 20.5/21.0 23.8/24.2
Loss Uniformity (dB) 0.4 0.6 0.8 1.0 1.5 2.0 2.5
Polarization Dependent Loss(dB) 0.1 0.1 0.1 0.20 0.25 0.30 0.4
Return Loss (dB)(P/S Grade) 55/50 55/50 55/50 55/50 55/50 55/50 55/50
Directivity (dB) 55 55 55 55 55 55 55
Wavelength Dependent Loss (dB) 0.3 0.3 0.3 0.3 0.5 0.5 0.5

Temperature Stability

(-40～85 ℃)(dB)

 0.4 0.4 0.4 0.5 0.5 0.5 0.5
Operating Temperature (℃) -40～80
Storage Temperature (℃) -40～85
Device Dimension (mm) 40×4×4 40×4×4 40×4×4 50×7×4 50×7×4 60×12×4 N/A
Module Dimension (mm) 100×80×10 120×80×18 141×115×18
Mini-Module Dimension (mm) 60×4×4 60×7×4 60×7×4 60×12×4 80×20×6 100×40×6 N/A

1x8 PLC Splitter with SC/APC connector Dimensions

1x8 PLC Fiber Splitter SC/APC Mini Module 900um Tube 1.5 Meter FTTH System

Package

1x8 PLC Fiber Splitter SC/APC Mini Module 900um Tube 1.5 Meter FTTH System

Telcordia 1209 & 1221 Test Results
Name of the test
Condition
Duration
Temperature- Humidity aging
85°C and 85% RH
7 days
Vibration
10 - 55Hz, 1.52mm double amplitude, in three axes
1 hour
Component Impact
Test Impact of 500g (mass ≤ 0.125kg), 1ms , half sine pulse
2 impacts
Temperature Cycling Test
-40 - 70°C, Ramp rate: 1°C /min, Dwell time > 15min
10 cycles
Temperature- Humidity cycling
-40 - 85°C , between 10°C and 23°C - 85% RH, at 85°C - 20%RH,
between °C and 85°C - maintain a linear change in RH,
below 10°C - uncontrolled RH
14 days
Water Immersion
43 ± 2°C , PH 5.5 ± 0.5
7 days
Fiber Side Pull test
0.23 kg load, 90° angle , 2 directions
5 seconds
Fiber Side Pull test
0.45 Kg load for Single Input Fiber, 1.5 Kg load for 8 Fiber Ribbon Outputs
5 seconds
Compact design, suitable for installation in outdoor fiber distribution box
The blockless splitter features small size, which is an intermediate choice between volume miniaturization and reliable fiber protection. It is suitable for installation in your system design and manufacturing. Many of our OEM customers in the FTTH, FTTX, PON, GOPN get the blockless splitters together with GEZHI 16 outdoor fiber distribution box. Contact with sales@gezhiphotonics.comfor complete application.

1x8 PLC Fiber Splitter SC/APC Mini Module 900um Tube 1.5 Meter FTTH System

Make to Order
PLC
Port Configutation
Package Style
Fiber Diameter
(Input/ Output)
Connector
(Input/Output)
Pigtail Length
PLC=PLC Splitter
102=1×2
ST=Steel tube, bare fiber
25=250μm
NO=None
15=1.5m
104=1×4
MM=Mini module
90=900μm
SCA=SC/APC
20=2.0m
108=1×8
FO=With fan-out
20=2.0mm
SCU=SC/UPC
30=3.0m
116=1×16
ABS=Pigtailed ABS box
30=3.0mm
LCA=LC/APC
XX=Customized
132=1×32
MP=Mini plug-in type
LCU=LC/UPC
164=1×64
LGX=Standard LGX
FCA=FC/APC
202=2×2
TR=Mounted on a Fiber Splice Tray
FCU=FC/UPC
204=2×4
1U=1U 19” rack mount chassis
STA=ST/APC
208=2×8
STU=ST/UPC
216=2×16
X=Customized
232=2×32
264=2×64
Notes for above:
1. When package style is ST, fiber diameter could be only 25=250um, connector could be only NO=none.
2. When package style is MM & FO, fiber diameter could be only 900um.
3. When package style is AB, fiber diameter could be 90=900um, 20=2.0mm, 30=3.00mm for optional.
4. When package style is MP, LGX, TR and 1U, "fiber diameter for input/output" & "pigtail length" could be left out, as the specific product would be made according to its configuration.
