Specifications
Brand Name :
GEZHI or OEM
Model Number :
CWDM12CH
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
China
MOQ :
1
Price :
Get Latest Price
Payment Terms :
T/T, Western Union
Supply Ability :
100000Channel per month
Delivery Time :
5-10 work days
Packaging Details :
paper box with foam
Product Name :
5G CWDM
Channel :
1x12
Channel Spcaing :
20nm
Wavelength :
1271~1371 & 1471~1571
Pakcage :
Insert ABS Box
Application :
5G Network
Description

1x12 Optical CWDM Mux Demux for 5G telecom

GEZHI 1x12 Optical CWDM Mux Demux for 5G telecom based on dielectric thin-film filter technology which with insert type ABS box package connect by LC/UPC adaptor. The wavelength of 1x12 Optical CWDM Mux Demux for 5G telecom is from 1271nm to 1571nm, transmission on a single optical fiber with only 3dB link insertion loss. The 1x12 Optical CWDM Mux Demux for 5G telecom has high channel isolation and can therefore be used in a bi-directional system. The module can be used as a multiplexer or de-multiplexer.

Features Applications

12 channels per fiber
Bi-directional

Low insertion loss
Can be used as multiplexer or de-multiplexer

Can be insert on 3U Rackmount Equipment

Optical video networks

Line Monitoring
Dark fiber networks

​Data Center
Broadcast contribution networks


Specification

Parameter

Unit

 1x12 CWDM Module
Mux Demux
Channel Wavelength nm 1271~1371nm & 1471~1571nm
Center wavelength
Accuracy		 nm ±0.5
Channel Spacing nm 20
Channel Passband
(@-0.5dB bandwidth		 nm >14
Max Insertion Loss dB <3.0 <3.0
Channel Ripple dB 0.3
Isolation Adjacent dB >30
Non-adjacent dB >40
Inertion Loss Temperature
Sensitivity		 dB/℃ <0.005
Wavelength Temperature
Shifting

nm/

℃

 <0.002
Polarization Dependent
Loss		 dB <0.1
Polarization Mode
Dispersion		 dB <0.1
Directivity dB >50
Return Loss dB >45
Maximum Power Handling mW 300
Opterating Temperature ℃ -5~+75
Storage Temperature ℃ -40~85
Package dimension mm L130x100x125

Note: 1. Customization is available.

2. Specified with connector

Ordering Information

CWDM XXX XX XX XX XX XX
Number of Channels Module type Cable type Fiber length Input connector

Output

connector
CWDM 01=1Channel
02=2 Channel
03=3 Channel
04=4 Channel
......
12=12Channel
16=16Channel
18=18Channel		 0=100x80x10 mm
1=142x102x14.5 mm
2=LGX Box
3=19″1U Rack
X=Others		 00=none
09=900um
Loose tube
20=2.0mm
30=3.0mm		 05=0.5m
10=1.0m
15=1.5m
30=3.0m
40=4.0m
50=5.0m
......		 0=none
LP=LC/UPC
LA=LC/APC
SP=SC/UPC
SA=SC/APC
FP=FC/UPC
FA=FC/APC
X=Customized

0=none
LP=LC/UPC
LA=LC/APC
SP=SC/UPC
SA=SC/APC
FP=FC/UPC
FA=FC/APC
X=Customized

1x12 Optical CWDM Mux Demux for 5G telecom Filter Cascading

1x12 Optical CWDM Mux Demux for 5G telecom

1x12 Optical CWDM Mux Demux for 5G telecom Solution

1x12 Optical CWDM Mux Demux for 5G telecom
