SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
Specifications
Brand Name :
SFT
Model Number :
SUCPA207
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Name :
Zinc alloy pillow block bearing
Material :
Chrome Steel GCR15
Cage :
Steel Cage.copper Cage.nylon Cage
Application :
Machinery
Housing material :
Iron Cast
Hardness :
60-65HRC
Description

Pillow block bearings insert radial ball bearing SUCPA207 agricultural machinery parts​

Product Description

To ensure effective sealing, pillow (plummer) blocks are available with a variety of special seal options and end covers. Benefits include a facility for easy mounting and dismounting of pre-assembled shafts.
Pillow block housing can be used with high-capacity spherical roller bearings or self-aligning ball bearings. They are manufactured from high-strength cast iron as standard but are also available in cast steel or spheroidal graphite cast iron. The housings have a re-lubrication facility and can be used with either oil or grease lubrication.

Insert bearings are designed to fit into bearing housings. They are often sold when assembled
into a suitable bearing housing but may also be bought alone. They have the characteristic of
being self aligning and can be easily mounted in a housin block. The housing is available in various
configurations.
Insert bearing with housing is a bearing unit which is with the rolling bearing and housing. Most of
the insert bearing with housing are made of outer diameter sphere, mounted together with the
bearing housing having a spherical bore. Various forms of structure, good versatility and inter
change ability.

Pillow Block Bearings Model

带座轴承型号 Bearing Unit No
轴径 Bore Dia
外形尺寸(毫米) Dimensions(mm)
d
h
a
e
b
mm
SUCPA201
12
30.2
76
52
40
SUCPA201-8
SUCPA202
15
SUCPA202-10
SUCPA203
17
SUCPA203-11
SUCPA204
20
30.2
76
52
40
SUCPA204-12
SUCPA205
25
36.5
84
56
38
SUCPA205-14
SUCPA205-15
SUCPA205-16
SUCPA206
30
42.9
94
66
50
SUCPA206-17
SUCPA206-18
SUCPA206-19
SUCPA206-20
SUCPA207
35
47.6
109
80
55
SUCPA207-20
SUCPA207-21
SUCPA207-22
SUCPA207-23
SUCPA208
40
49.2
116
84
58
SUCPA208-24
SUCPA208-25
SUCPA209
45
54.2
120
90
60
SUCPA209-26
SUCPA209-27
SUCPA209-28
SUCPA210
50
57.2
130
94
64
SUCPA210-29
SUCPA210-30
SUCPA210-31
SUCPA210-32

SUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery PartsSUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery PartsSUCPA207 Pillow Block Bearings Insert Radial Ball Bearing Agricultural Machinery Parts
